GIDINGS&LEWIS PDL-1020驱动器  PDF资料

1.产 品 资 料 介 绍：

GIDINGS&LEWIS PDL-1020 驱动器

产品概述

Giddings & Lewis PDL-1020 驱动器是一款用于数控机床和自动化系统的伺服/步进电机驱动模块，主要功能是接收伺服控制板或 CPU 板的控制指令，将其转换为电机驱动信号，实现电机的精准位置、速度和加速度控制。它是机床执行系统中关键的动力控制单元。

技术特点

• 高精度控制：支持位置、速度及加速度的闭环控制，实现高精度加工。

• 多种电机兼容：适配伺服电机和步进电机，支持不同类型的执行系统。

• 实时响应：快速处理控制信号，满足高速加工和多轴联动需求。

• 模块化设计：便于安装、维护和系统扩展。

• 工业级可靠性：抗干扰、耐振动，适应复杂机床环境。

• 保护功能：具备过载、过流、过热保护，保障电机及系统安全。

应用领域

1. 数控镗床与铣床
   控制主轴、工作台和刀架的运动，实现高精度加工和复杂工件加工。

2. 立式车床及车铣复合机床
   协调多轴动作，实现车削、铣削及钻削等复合加工工序。

3. 自动化生产线
   驱动机械手臂或其他执行单元，实现生产线设备动作同步和精确控制。

4. 机器人及精密机械设备
   提供高速、高精度运动控制，适用于精密加工、装配或定位。

5. 机床改造与升级
   在老旧设备数控化改造中，作为核心驱动模块，提高运动控制精度和系统稳定性

英文资料：

GIDINGS&LEWIS PDL-1020 Driver

Product Overview

The Giddings&Lewis PDL-1020 driver is a servo/stepper motor drive module used in CNC machine tools and automation systems. Its main function is to receive control instructions from the servo control board or CPU board, convert them into motor drive signals, and achieve precise position, speed, and acceleration control of the motor. It is a key power control unit in the machine tool execution system.

Technical Features

High precision control: supports closed-loop control of position, velocity, and acceleration to achieve high-precision machining.

Multiple motor compatibility: compatible with servo motors and stepper motors, supporting different types of execution systems.

Real time response: Quickly process control signals to meet the requirements of high-speed machining and multi axis linkage.

Modular design: easy to install, maintain, and expand the system.

Industrial grade reliability: anti-interference, vibration resistance, suitable for complex machine tool environments.

Protection function: It has overload, overcurrent, and overheating protection to ensure the safety of the motor and system.

Application field

CNC boring and milling machines

Control the movement of the spindle, worktable, and tool holder to achieve high-precision machining and complex workpiece machining.

Vertical lathe and milling composite machine tool

Coordinate multi axis actions to achieve composite machining processes such as turning, milling, and drilling.

Automatic production line

Drive robotic arms or other execution units to achieve synchronized and precise control of production line equipment movements.

Robots and precision mechanical equipment

Provide high-speed and high-precision motion control, suitable for precision machining, assembly, or positioning.

Machine tool transformation and upgrading

In the numerical control transformation of old equipment, as the core driving module, improving the precision of motion control and system stability
