GIDINGS&LEWIS 502-02815-01 编码器模块

产品概述

Giddings & Lewis 502-02815-01 编码器模块是一种用于数控机床和自动化系统的反馈信号处理模块。它主要用于接收旋转编码器（Encoder）传感器输出的位置信号或速度信号，并将其转换为数控系统或伺服控制器可识别的标准信号，实现对机床轴的精确定位和速度控制。

技术特点

• 高精度信号解析：处理来自旋转编码器的增量或绝对位置信号，保证精确反馈。

• 闭环控制支持：与伺服驱动器或执行控制板配合，实现高速、高精度的闭环控制。

• 多通道支持：可同时接入多个编码器，实现多轴监控。

• 模块化设计：易于安装、更换和系统扩展。

• 工业环境适应性：抗干扰、耐振动，适合重型机床环境。

应用领域

1. 数控镗床、铣床
   提供主轴、工作台和刀架等轴的精确位置和速度反馈，实现高精度加工。

2. 立式车床及车铣复合中心
   协调多轴动作，实现复杂零件加工和多工序联动。

3. 自动化生产线
   用于机械手或多轴执行单元的精确位置监控，保证动作同步。

4. 机床改造与升级
   在老旧设备数控化改造中，提供编码器信号接口，提升运动控制精度。

5. 机器人及精密机械设备
   支持高精度机械臂、自动化装配或精密加工设备的运动反馈。

英文资料：

GIDINGS&LEWIS 502-02815-01 Encoder Module

Product Overview

The Giddings&Lewis 502-02815-01 encoder module is a feedback signal processing module used in CNC machine tools and automation systems. It is mainly used to receive the position signal or speed signal output by the rotary encoder sensor, and convert it into a standard signal recognizable by the numerical control system or servo controller, achieving precise positioning and speed control of the machine tool axis.

Technical Features

High precision signal analysis: Processing incremental or absolute position signals from rotary encoders to ensure accurate feedback.

Closed loop control support: In conjunction with servo drives or execution control boards, achieve high-speed and high-precision closed-loop control.

Multi channel support: Multiple encoders can be connected simultaneously to achieve multi axis monitoring.

Modular design: easy to install, replace, and expand the system.

Industrial environment adaptability: anti-interference, vibration resistant, suitable for heavy-duty machine tool environments.

Application field

CNC boring and milling machines

Provide precise position and speed feedback for axes such as spindle, worktable, and tool holder to achieve high-precision machining.

Vertical lathe and milling composite center

Coordinate multi axis actions to achieve complex part machining and multi process linkage.

Automatic production line

Used for precise position monitoring of robotic arms or multi axis execution units to ensure action synchronization.

Machine tool transformation and upgrading

In the numerical control transformation of old equipment, providing encoder signal interfaces to improve motion control accuracy.

Robots and precision mechanical equipment

Support motion feedback for high-precision robotic arms, automated assembly, or precision machining equipment.
