GIDINGS&LEWIS  501-04715-01伺服控制板 PDF资料

1.产 品 资 料 介 绍：

GIDINGS&LEWIS 501-04715-01 伺服控制板

产品概述

Giddings & Lewis 501-04715-01 伺服控制板是一种用于数控机床与自动化设备的核心控制模块，主要负责对伺服电机的驱动与反馈信号进行处理与控制。它在数控系统中承担运动控制核心功能，将数控指令转化为对伺服驱动器和电机的精确控制信号，从而实现高速、高精度的机床运动。

技术特点

• 高精度运动控制：实现位置、速度和加速度的精确调节。

• 闭环控制：支持编码器、旋转变压器等反馈信号的实时处理，保证伺服系统稳定运行。

• 多轴协调：可同时控制多个伺服轴，适合复杂联动加工。

• 实时响应：具备低延迟的控制性能，满足高速加工需求。

• 工业级设计：抗干扰性能强，适应重载机床环境。

应用领域

1. 数控镗床与铣床
   控制主轴和进给伺服系统，实现高精度切削与大工件加工。

2. 立式车床、车铣复合机床
   协调多个伺服轴的联动控制，支持复杂曲面加工和多工序加工。

3. 自动化生产线
   管理执行单元的伺服动作，保证设备间的同步与高效运转。

4. 机器人与机械臂
   提供精密运动控制，适合对动态响应要求高的自动化作业。

5. 机床改造与升级
   在老旧设备的数控化升级中，作为伺服控制核心模块，提升机床精度与效率

英文资料：

GIDINGS&LEWIS 501-04715-01 servo control board

Product Overview

Giddings&Lewis 501-04715-01 servo control board is a core control module used for CNC machine tools and automation equipment, mainly responsible for processing and controlling the drive and feedback signals of servo motors. It undertakes the core function of motion control in the CNC system, converting CNC instructions into precise control signals for servo drives and motors, thereby achieving high-speed and high-precision machine tool motion.

Technical Features

High precision motion control: achieving precise adjustment of position, velocity, and acceleration.

Closed loop control: supports real-time processing of feedback signals such as encoders and rotary transformers to ensure stable operation of the servo system.

Multi axis coordination: can control multiple servo axes simultaneously, suitable for complex linkage machining.

Real time response: With low latency control performance, it meets the requirements of high-speed machining.

Industrial grade design: Strong anti-interference performance, suitable for heavy-duty machine tool environments.

Application field

CNC boring and milling machines

Control the spindle and feed servo system to achieve high-precision cutting and large workpiece machining.

Vertical lathe, milling and turning composite machine tool

Coordinate the linkage control of multiple servo axes, supporting complex surface machining and multi process machining.

Automatic production line

Manage the servo actions of the execution unit to ensure synchronization and efficient operation between devices.

Robots and robotic arms

Provide precise motion control, suitable for automated operations that require high dynamic response.

Machine tool transformation and upgrading

In the CNC upgrade of old equipment, as the core module of servo control, it improves the accuracy and efficiency of machine tools
