GIDINGS&LEWIS  501-03209-00执行控制板 PDF资料

1.产 品 资 料 介 绍：

GIDINGS&LEWIS 501-03209-00 执行控制板

产品概述

Giddings & Lewis 501-03209-00 执行控制板是一种关键的数控机床控制模块，主要负责执行层的动作控制和指令下发。它通常安装在数控系统或电控柜中，接收上位 CPU 板或控制单元的指令，并将其转化为对伺服驱动、执行机构以及外围设备的控制信号，是数控系统中连接“逻辑控制”与“实际执行”的核心桥梁。

技术特点

• 指令执行：将上位机发出的运动、加工或逻辑命令转化为实际的控制信号。

• 多通道控制：可同时管理多个伺服轴、I/O 接口和外围设备。

• 实时性强：确保机床运动控制的快速响应与高精度。

• 模块化设计：支持插入式安装，便于系统扩展与更换。

• 抗干扰能力：电路优化设计，适合重型机床复杂环境。

应用领域

1. 数控镗床、铣床
   管理工作台、主轴、刀架等多轴联动的执行控制，确保大工件的高精度加工。

2. 立式车床与车铣复合中心
   协调车削、铣削、钻削等多工序复合加工中的执行机构动作。

3. 伺服驱动控制
   作为 CPU 与伺服驱动器之间的中间层，实现对电机的速度、位置和加速度控制。

4. 自动化生产线
   用于机床在生产线中的执行单元控制，确保与上下游设备的动作同步。

5. 机床升级与改造
   在老旧 G&L 设备的数控化改造中，作为核心执行控制模块，提升机床性能。

英文资料：

GIDINGS&LEWIS 501-03209-00 Execution Control Board

Product Overview

The Giddings&Lewis 501-03209-00 Execution Control Board is a critical control module for CNC machine tools, mainly responsible for action control and instruction issuance at the execution level. It is usually installed in CNC systems or electrical control cabinets, receiving instructions from the upper CPU board or control unit, and converting them into control signals for servo drives, actuators, and peripheral devices. It is the core bridge connecting "logical control" and "actual execution" in CNC systems.

Technical Features

Instruction execution: Convert the motion, processing, or logic commands issued by the upper computer into actual control signals.

Multi channel control: capable of managing multiple servo axes, I/O interfaces, and peripheral devices simultaneously.

Strong real-time performance: ensuring fast response and high precision of machine tool motion control.

Modular design: Supports plug-in installation for easy system expansion and replacement.

Anti interference capability: optimized circuit design, suitable for complex environments of heavy-duty machine tools.

Application field

CNC boring and milling machines

Manage the execution control of multi axis linkage such as workbench, spindle, and tool holder to ensure high-precision machining of large workpieces.

Vertical lathe and milling composite center

Coordinate the actuator actions in multi process composite machining such as turning, milling, and drilling.

Servo drive control

As an intermediate layer between the CPU and the servo driver, it controls the speed, position, and acceleration of the motor.

Automatic production line

Used for controlling the execution unit of machine tools in the production line, ensuring synchronization with the actions of upstream and downstream equipment.

Machine tool upgrade and renovation

In the numerical control transformation of old G&L equipment, the core execution control module is used to improve the performance of the machine tool.

2.产      品      展      示
