GIDINGS&LEWIS 501-92501-00线性英寸标尺 PDF资料

1.产 品 资 料 介 绍：

GIDINGS&LEWIS 501-92501-00 线性英寸标尺

产品概述

Giddings & Lewis 501-92501-00 线性英寸标尺是一种精密位置测量组件，通常用于大型数控机床、镗床或铣床的直线轴定位与反馈。该标尺以英寸为测量单位，主要为机床提供高精度的直线位移检测信号，是数控系统实现精密加工控制的重要部件。

技术特点

• 高精度：以英寸单位进行刻度测量，保证大行程加工中的定位精度。

• 可靠耐用：适用于重型机床环境，能抵御振动、粉尘和切削液影响。

• 反馈信号：为机床数控系统提供实时位移和位置反馈。

• 兼容性强：适配 G&L 的多种数控机床控制系统。

应用领域

1. 大型镗床与铣床
   用于主轴或工作台的直线位置检测，确保大行程下的精准定位。

2. 立式车削中心与车铣复合机床
   提供刀架或工作台的精确位置反馈，提高复杂曲面加工精度。

3. 数控加工中心
   在自动化加工过程中，实时监控和调整轴运动，保证加工质量。

4. 机床改造与升级
   可用于老旧设备的数控化改造，提升定位和测量精度。

5. 检测与校准应用
   在设备维护或工件检测中，作为参考基准标尺，提高工艺一致性。

产品优势

• 精度保障：保证大型工件的加工精度和重复性。

• 提升效率：减少因位置误差导致的返工。

• 稳定可靠：适应工业现场复杂工况。

• 长寿命设计：耐磨、耐环境影响，延长使用周期。

英文资料：

GIDINGS&LEWIS 501-92501-00 linear inch ruler

Product Overview

Giddings&Lewis 501-92501-00 linear inch ruler is a precision position measurement component commonly used for linear axis positioning and feedback in large CNC machine tools, boring machines, or milling machines. This ruler is measured in inches and mainly provides high-precision linear displacement detection signals for machine tools. It is an important component for CNC systems to achieve precision machining control.

Technical Features

High precision: Measuring in inches to ensure positioning accuracy during large stroke machining.

Reliable and durable: suitable for heavy-duty machine tool environments, able to resist vibration, dust, and cutting fluid effects.

Feedback signal: Provide real-time displacement and position feedback for the CNC system of the machine tool.

Strong compatibility: Suitable for various CNC machine control systems of G&L.

Application field

Large boring and milling machines

Used for linear position detection of spindle or worktable, ensuring precise positioning under large stroke.

Vertical turning center and turning milling composite machine tool

Provide precise position feedback for tool holders or workbenches to improve the precision of complex surface machining.

CNC machining center

Real time monitoring and adjustment of axis motion during automated machining processes to ensure machining quality.

Machine tool transformation and upgrading

Can be used for CNC transformation of old equipment to improve positioning and measurement accuracy.

Testing and Calibration Applications

In equipment maintenance or workpiece inspection, use a reference benchmark ruler to improve process consistency.

Product advantages

Accuracy guarantee: Ensure the machining accuracy and repeatability of large workpieces.

Improve efficiency: Reduce rework caused by positional errors.

Stable and reliable: Suitable for complex working conditions in industrial sites.

Long life design: wear-resistant, resistant to environmental influences, and extends the service life.

2.产      品      展      示
