GIDINGS&LEWIS 501-03437-00变频器模块 PDF资料

1.产 品 资 料 介 绍：

GIDINGS&LEWIS 501-03437-00 变频器模块

产品应用领域

1. 数控机床主轴控制
   用于CNC车床、铣床和镗床，实现主轴转速调节、加减速控制和稳定运行。

2. 工业自动化驱动系统
   为传送带、电机泵或风机等提供可调速控制，提高生产线灵活性和效率。

3. 伺服和多轴控制系统
   配合伺服驱动器使用，实现多轴电机的精确速度和转矩控制，支持复杂运动轨迹。

4. 机器人及机械臂运动控制
   调节电机速度和转矩，保证机械臂动作平滑、定位精确和重复性高。

5. 节能与过程优化
   在能源管理系统或工艺流程中，通过变频控制实现能耗优化及系统负荷调节。

6. 实验与测试平台
   用于研发和测试系统，实现电机速度、负载和加速度的可控实验条件。

7. 多设备集成控制
   可与控制器、I/O模块及接口板协同工作，实现整套自动化系统的协调驱动。

产品特点

1. 高精度速度控制：支持闭环控制，实现微小速度调节和稳定转速输出。

2. 动态响应快：加减速曲线可调，适应高动态运动需求。

3. 兼容性强：可与各种伺服或异步电机匹配，适应不同工业设备。

4. 节能效果显著：优化电机运行效率，降低功耗和机械磨损。

5. 模块化设计：标准化接口，方便安装、替换及扩展。

6. 工业级耐用性：抗振动、耐高温，适合长期工业现场运行。

7. 安全保护功能：具备过流、过压、过热和短路保护，提高系统可靠性。

8. 多模式控制：支持手动、自动和远程控制模式，便于系统集成和灵活调节。

英文资料：

GIDINGS&LEWIS 501-03437-00 frequency converter module

Product application areas

CNC machine tool spindle control

Used for CNC lathes, milling machines, and boring machines to achieve spindle speed adjustment, acceleration and deceleration control, and stable operation.

Industrial automation drive system

Provide adjustable speed control for conveyor belts, motor pumps, or fans to improve the flexibility and efficiency of production lines.

Servo and multi axis control system

Used in conjunction with servo drives to achieve precise speed and torque control of multi axis motors, supporting complex motion trajectories.

Robot and robotic arm motion control

Adjust the motor speed and torque to ensure smooth movement, precise positioning, and high repeatability of the robotic arm.

Energy saving and process optimization

In energy management systems or process flows, energy consumption optimization and system load regulation are achieved through frequency conversion control.

Experimental and testing platform

Used for developing and testing systems to achieve controllable experimental conditions for motor speed, load, and acceleration.

Multi device integrated control

It can work in conjunction with controllers, I/O modules, and interface boards to achieve coordinated driving of the entire automation system.

Product Features

High precision speed control: supports closed-loop control, achieving small speed adjustment and stable speed output.

Fast dynamic response: The acceleration and deceleration curves are adjustable to meet high dynamic motion requirements.

Strong compatibility: It can be matched with various servo or asynchronous motors to adapt to different industrial equipment.

Significant energy-saving effect: optimizing motor operating efficiency, reducing power consumption and mechanical wear.

Modular design: Standardized interfaces for easy installation, replacement, and expansion.

Industrial grade durability: resistant to vibration, high temperature, suitable for long-term industrial site operation.

Safety protection function: It has overcurrent, overvoltage, overheating, and short circuit protection to improve system reliability.

Multi mode control: supports manual, automatic, and remote control modes, facilitating system integration and flexible adjustment.

2.产      品      展      示
