AEG Modicon AS-BADU-205 模拟输入处理器
产品说明
一、产品定位
AS-BADU-205 是 Modicon 系列 PLC 系统中的模拟量输入处理模块，用于采集现场传感器的模拟信号并转换为数字信号，供控制器处理。它是实现温度、压力、流量、液位等连续量控制的重要模块。
二、核心功能
多通道模拟信号采集，将现场电压或电流信号转换为 PLC 可处理的数字量。
支持信号线性化、缩放及过滤，提高测量精度。
内置故障检测功能，可监测开路、短路或信号异常。
与 PLC CPU 通信同步，确保模拟数据实时更新。
提供模块状态指示，便于现场维护和故障排查。
三、产品特点
高精度、高稳定性，保证连续量测量的可靠性。
抗干扰能力强，适应复杂工业现场环境。
模块化设计，可方便安装于标准机架内。
支持多种类型模拟信号输入（如 0–10V、4–20mA）。
工业级设计，适合长时间连续工作。
四、典型应用
化工、冶金、制药、食品等行业的过程控制系统。
温度、压力、流量、液位等模拟量的采集与监控。
自动化生产线控制柜中的模拟信号输入管理。
与其他 Modicon 模块配合，实现闭环控制。
老旧系统升级或扩展项目中的模拟输入单元。
AEG MODICON AS-BADU-205模拟 输入处理器 英文介绍
AEG Modicon AS-BADU-205 Analog Input Processor
Product Description
1、 Product positioning
AS-BADU-205 is an analog input processing module in the Modicon series PLC system, used to collect analog signals from field sensors and convert them into digital signals for controller processing. It is an important module for achieving continuous control of temperature, pressure, flow rate, liquid level, and other parameters.
2、 Core functions
Multi channel analog signal acquisition, converting on-site voltage or current signals into digital quantities that can be processed by PLC.
Support signal linearization, scaling, and filtering to improve measurement accuracy.
Built in fault detection function, capable of monitoring open circuits, short circuits, or signal abnormalities.
Synchronize with PLC CPU communication to ensure real-time updates of analog data.
Provide module status indication for easy on-site maintenance and troubleshooting.
3、 Product Features
High precision and stability ensure the reliability of continuous measurement.
Strong anti-interference ability and adaptability to complex industrial site environments.
Modular design, easy to install in standard racks.
Supports multiple types of analog signal inputs (such as 0-10V, 4-20mA).
Industrial grade design, suitable for long-term continuous work.
4、 Typical applications
Process control systems for industries such as chemical, metallurgical, pharmaceutical, and food.
Collection and monitoring of analog quantities such as temperature, pressure, flow rate, and liquid level.
Analog signal input management in the control cabinet of the automated production line.
Collaborate with other Modicon modules to achieve closed-loop control.
Analog input unit in old system upgrade or expansion projects.
AEG MODICON AS-BADU-205模拟 输入处理器 产品展示
