AEG MODICON AS-BDAP-218输出模块 PDF资料
1.产 品 资 料 介 绍：
AEG Modicon AS-BDAP-218 输出模块
产品说明
一、产品定位
AS-BDAP-218 是 Modicon 系列 PLC 系统中的数字量输出模块，主要用于将 PLC 内部控制信号传递给执行器、继电器、电磁阀或其他外部设备，实现现场控制动作。
二、核心功能
接收 PLC CPU 发出的数字控制信号并驱动外部负载。
支持多通道输出，可同时控制多个执行点。
提供模块状态指示，方便运行监控和故障排查。
支持系统通信同步，保证输出信号与 PLC 程序执行一致。
可与 Modicon 机架和其他模块无缝集成，构建灵活控制系统。
三、产品特点
输出电平稳定、响应速度快，确保控制动作及时可靠。
内置保护设计，防止短路或过载损坏模块及负载。
模块化安装，易于维护、更换和扩展。
工业级设计，适合高温、湿度及振动条件的现场环境。
兼容 Modicon 系列机架和标准 I/O 布局，便于系统升级。
四、典型应用
驱动继电器、电磁阀、指示灯等现场控制设备。
自动化生产线上的开关控制或设备启动/停止。
工厂成套设备和控制柜中的数字输出管理。
配合传感器或逻辑控制，实现安全和报警系统。
老旧 Modicon 系统升级或扩展项目中的数字输出单元。
AEG MODICON AS-BDAP-218输出模块 英文介绍
AEG Modicon AS-BDAP-218 Output Module
Product Description
1、 Product positioning
AS-BDAP-218 is a digital output module in the Modicon series PLC system, mainly used to transmit internal control signals of the PLC to actuators, relays, solenoid valves or other external devices to achieve on-site control actions.
2、 Core functions
Receive digital control signals from PLC CPU and drive external loads.
Supports multi-channel output and can control multiple execution points simultaneously.
Provide module status indication for easy operation monitoring and troubleshooting.
Support system communication synchronization to ensure consistency between output signals and PLC program execution.
It can seamlessly integrate with Modicon racks and other modules to build a flexible control system.
3、 Product Features
Stable output level and fast response speed ensure timely and reliable control actions.
Built in protection design to prevent short circuit or overload damage to modules and loads.
Modular installation, easy to maintain, replace, and expand.
Industrial grade design, suitable for on-site environments with high temperature, humidity, and vibration conditions.
Compatible with Modicon series rack and standard I/O layout for easy system upgrades.
4、 Typical applications
Drive on-site control equipment such as relays, solenoid valves, indicator lights, etc.
Switch control or equipment start/stop on automated production lines.
Digital output management in factory equipment and control cabinets.
Cooperate with sensors or logic control to achieve safety and alarm systems.
The digital output unit in the upgrade or expansion project of the old Modicon system.
AEG MODICON AS-BDAP-218输出模块 产品展示
