AEG MODICON AS-B875-200热电偶输入模块 PDF资料
1.产 品 资 料 介 绍：
AEG Modicon AS-B875-200 热电偶输入模块
产品说明
一、产品定位
AS-B875-200 是 Modicon 系列 PLC 系统中的模拟量输入模块，专门用于热电偶信号采集。它能够将热电偶产生的微小电压信号转换为可供 PLC 处理的数字量，实现高精度温度监控和控制。
二、核心功能
支持多通道热电偶输入，实时采集温度信号。
内置冷端补偿和线性化功能，提高温度测量精度。
将模拟信号转换为数字量输出，供 PLC CPU 处理。
提供状态监控和故障报警功能，可检测开路或异常信号。
与 Modicon 控制系统同步刷新数据，保证温控精度和实时性。
三、产品特点
高精度输入，适合工业现场对温度控制要求严格的应用。
抗干扰能力强，保证热电偶信号在复杂电磁环境下稳定传输。
模块化设计，易于安装和更换，支持机架式布置。
可同时处理多种类型热电偶，如 K 型、J 型等（具体型号依据规格书）。
工业级可靠性设计，适合长时间连续工作。
四、典型应用
化工、冶金、钢铁、水泥等生产过程的温度监控。
自动化炉温、烘箱或热处理设备的温度控制。
食品加工、制药等对温控精度要求高的工艺环节。
工厂成套设备和控制柜内的多点温度采集系统。
老旧 Modicon 系统升级或替换项目中的温度测量单元。
AEG MODICON AS-B875-200热电偶输入模块 英文介绍
AEG Modicon AS-B875-200 Thermocouple Input Module
Product Description
1、 Product positioning
AS-B875-200 is an analog input module in the Modicon series PLC system, specifically designed for thermocouple signal acquisition. It can convert the small voltage signals generated by thermocouples into digital quantities that can be processed by PLC, achieving high-precision temperature monitoring and control.
2、 Core functions
Support multi-channel thermocouple input and real-time temperature signal acquisition.
Built in cold end compensation and linearization function to improve temperature measurement accuracy.
Convert analog signals into digital outputs for processing by the PLC CPU.
Provide status monitoring and fault alarm functions, which can detect open circuit or abnormal signals.
Synchronize with Modicon control system to refresh data, ensuring temperature control accuracy and real-time performance.
3、 Product Features
High precision input, suitable for applications with strict temperature control requirements in industrial sites.
Strong anti-interference ability ensures stable transmission of thermocouple signals in complex electromagnetic environments.
Modular design, easy to install and replace, supports rack mounted layout.
It can handle multiple types of thermocouples simultaneously, such as K-type, J-type, etc. (specific models according to specifications).
Industrial grade reliability design, suitable for long-term continuous operation.
4、 Typical applications
Temperature monitoring in production processes such as chemical, metallurgical, steel, cement, etc.
Temperature control of automated furnaces, ovens, or heat treatment equipment.
Food processing, pharmaceuticals, and other processes that require high temperature control accuracy.
Multi point temperature acquisition system inside the factory's complete equipment and control cabinet.
Upgrade or replace the temperature measurement unit in the old Modicon system project.
AEG MODICON AS-B875-200热电偶输入模块 产品展示
