AEG MODICON AS-B872-200模拟电压输出模块 PDF资料
1.产 品 资 料 介 绍：
AEG Modicon AS-B872-200 模拟电压输出模块
产品说明
一、产品定位
AS-B872-200 是 Modicon 系列 PLC 系统中使用的模拟量输出模块，主要用于将控制系统中的数字信号转换为可驱动现场设备的模拟电压信号，适用于控制阀门、电机、变频器等需要连续模拟控制的装置。
二、核心功能
将 PLC 内部数字控制信号转换为线性模拟电压输出。
支持多通道输出，能够同时驱动多个模拟执行器。
输出电压范围可满足工业现场常用标准，例如 0–10V 或 ±10V（具体参考规格书）。
提供模块状态指示，方便运行监控与故障判断。
与 Modicon 系统通信同步，确保输出信号随 PLC 指令及时更新。
三、产品特点
输出精度高，响应速度快，保证控制信号的稳定性。
电气隔离设计，增强抗干扰能力，保护 PLC 与现场设备安全。
模块化安装，与其他 800 系列模块兼容，可灵活插入机架。
工业级设计，适应长时间连续工作及现场环境条件。
易于维护和更换，便于系统扩展或升级。
四、典型应用
控制阀门位置或液压、电动执行器的开度。
变频器或伺服驱动器的模拟速度控制。
温控、压力控制、流量控制等过程自动化环节。
工厂生产线、成套设备或机柜内的连续控制信号输出。
与其他 PLC 模块配合，实现模拟量信号闭环控制。
AEG MODICON AS-B872-200模拟电压输出模块 英文介绍
AEG Modicon AS-B872-200 Analog Voltage Output Module
Product Description
1、 Product positioning
AS-B872-200 is an analog output module used in the Modicon series PLC system, mainly used to convert digital signals in the control system into analog voltage signals that can drive field devices. It is suitable for controlling devices such as valves, motors, and frequency converters that require continuous analog control.
2、 Core functions
Convert the internal digital control signals of the PLC into linear analog voltage outputs.
Supports multi-channel output and can drive multiple analog actuators simultaneously.
The output voltage range can meet the commonly used standards in industrial sites, such as 0-10V or ± 10V (refer to the specification sheet for details).
Provide module status indication for easy operation monitoring and fault diagnosis.
Synchronize communication with Modicon system to ensure timely updates of output signals with PLC instructions.
3、 Product Features
High output accuracy, fast response speed, ensuring the stability of control signals.
Electrical isolation design enhances anti-interference capability and protects the safety of PLC and on-site equipment.
Modular installation, compatible with other 800 series modules, and can be flexibly inserted into the rack.
Industrial grade design, suitable for long-term continuous work and on-site environmental conditions.
Easy to maintain and replace, convenient for system expansion or upgrade.
4、 Typical applications
Control the position of valves or the opening of hydraulic and electric actuators.
Analog speed control of frequency converters or servo drives.
Automation processes such as temperature control, pressure control, and flow control.
Continuous control signal output in factory production lines, complete sets of equipment, or cabinets.
Cooperate with other PLC modules to achieve closed-loop control of analog signals.
AEG MODICON AS-B872-200模拟电压输出模块 产品展示
