AEG MODICON 520VPU19200手持示教器 PDF资料
1.产 品 资 料 介 绍：
AEG Modicon 520VPU19200 手持示教器
产品说明
一、产品定位
520VPU19200 是 AEG Modicon 系统中使用的便携式手持示教器，主要用于设备调试、参数设定、简单监控与现场维护。它适合在无上位机、无操作面板的情况下，对控制系统进行直接操作和数据查看。
二、主要功能
提供基本的参数读取与修改能力，便于快速调整设备运行状态。
支持查看输入输出状态，协助现场检查 I/O 点是否正常。
可对 PLC 内部寄存器或变量进行简单访问，便于故障定位。
提供手动控制按键，可用于设备点动、试运行与校准。
具备功能键、数字键、方向键等基础操作界面，适合现场快速操作。
三、产品特点
体积小、易携带，适合设备调试人员随身使用。
操作界面简洁，学习成本低，对于老系统尤其方便。
显示清晰，能够在光线较差的环境中依然可靠读取数据。
通讯稳定，与对应的 Modicon 控制系统可即插即用。
工业级外壳设计，耐用、耐冲击，适用于现场环境。
四、典型应用
自动化设备现场调试。
工厂生产线的维护和快速排障。
旧款 Modicon 控制系统的参数修改或程序检查。
设备点动测试和动作校准。
无需电脑即可完成的快速设定场景。
AEG MODICON 520VPU19200手持示教器 英文介绍
AEG Modicon 520VPU19200 handheld teaching pendant
Product Description
1、 Product positioning
520VPU19200 is a portable handheld teaching pendant used in the AEG Modicon system, mainly for equipment debugging, parameter setting, simple monitoring, and on-site maintenance. It is suitable for direct operation and data viewing of control systems without an upper computer or operation panel.
2、 Main functions
Provide basic parameter reading and modification capabilities for quick adjustment of device operating status.
Support viewing input/output status and assist in on-site inspection of whether I/O points are normal.
Easy access to internal registers or variables of PLC for fault location.
Provide manual control buttons that can be used for device jogging, trial operation, and calibration.
Equipped with basic operation interfaces such as function keys, numeric keys, and directional keys, suitable for quick on-site operation.
3、 Product Features
Small in size and easy to carry, suitable for equipment debugging personnel to use with them.
The operation interface is simple, the learning cost is low, and it is particularly convenient for old systems.
Clear display, able to reliably read data even in poor lighting environments.
Stable communication and plug and play compatibility with the corresponding Modicon control system.
Industrial grade shell design, durable, impact resistant, suitable for on-site environments.
4、 Typical applications
On site debugging of automation equipment.
Maintenance and rapid troubleshooting of factory production lines.
Parameter modification or program inspection of the old Modicon control system.
Equipment jog testing and motion calibration.
Quickly set up scenarios without the need for a computer.
AEG MODICON 520VPU19200手持示教器 产品展示
