AEG MODICON PC-Z984-785控制系统 PDF资料
1.产 品 资 料 介 绍：
AEG Modicon PC-Z984-785 控制系统
产品说明
一、产品定位
PC-Z984-785 属于 Modicon 984 系列的高等级控制系统，是为中大型自动化工程设计的核心控制单元。它主要承担逻辑运算、数据处理、通讯管理以及对整个 I/O 系统的集中调度，是一套可靠度较高的工业控制平台。
二、核心功能
完成 PLC 程序的循环执行，包括逻辑控制、顺序控制与模拟量运算。
统一管理现场输入输出数据，确保控制命令与外部信号实时同步。
提供稳定的通讯能力，可与多种远程 I/O、现场设备及操作终端进行交互。
支持较大容量的用户程序，适用于复杂工艺与大型控制流程。
具备内部诊断与故障显示，实现对系统健康状态的实时监测。
三、产品特点
运算性能稳定，适合长时间连续运行的工业现场。
扩展性强，可搭配不同的 I/O 模块、通讯模块、电源模块与远程机架。
抗干扰能力突出，能在电磁环境复杂的工厂条件下保持稳定。
模块化结构设计，方便维护与更换，适合工程项目长期使用。
支持多协议架构，可兼容多种现场网络与外部装置。
四、典型应用
电力行业的保护与监控系统。
化工、钢铁、水泥等连续性生产流程。
大型机械装备、成套控制柜与自动化生产线。
水处理与市政工程的集中控制系统。
老旧设备的替换与扩容项目，尤其是原本基于 984 系列的平台。
AEG MODICON PC-Z984-785控制系统 英文介绍
AEG Modicon PC-Z984-785 Control System
Product Description
1、 Product positioning
PC-Z984-785 belongs to the Modicon 984 series of high-level control systems and is the core control unit designed for medium and large-scale automation projects. It is mainly responsible for logic operation, data processing, communication management and centralized scheduling of the entire I/O system. It is a highly reliable industrial control platform.
2、 Core functions
Complete the loop execution of PLC programs, including logic control, sequence control, and analog calculation.
Unified management of on-site input and output data to ensure real-time synchronization between control commands and external signals.
Provide stable communication capabilities and enable interaction with various remote I/O, on-site devices, and operating terminals.
Support large capacity user programs, suitable for complex processes and large-scale control procedures.
Equipped with internal diagnosis and fault display, achieving real-time monitoring of system health status.
3、 Product Features
Stable computational performance, suitable for industrial sites that operate continuously for long periods of time.
Strong scalability, can be paired with different I/O modules, communication modules, power modules, and remote racks.
Outstanding anti-interference ability, able to maintain stability under complex factory conditions in electromagnetic environments.
Modular structural design, convenient for maintenance and replacement, suitable for long-term use in engineering projects.
Supports multi protocol architecture and is compatible with various on-site networks and external devices.
4、 Typical applications
Protection and monitoring system for the power industry.
Continuous production processes such as chemical, steel, cement, etc.
Large scale mechanical equipment, complete control cabinets, and automated production lines.
Centralized control system for water treatment and municipal engineering.
The replacement and expansion project of old equipment, especially the platform originally based on the 984 series.
AEG MODICON PC-Z984-785控制系统 产品展示
