AEG MODICON AS-J892-101远程 I/O 处理器 PDF资料
1.产 品 资 料 介 绍：
AEG Modicon AS-J892-101 远程 I/O 处理器
产品说明
一、产品定位
AS-J892-101 是 Modicon 800 系列中的远程 I/O 通信处理模块，用于在主控制器与远程机架之间建立稳定的数据传输通道。它主要负责远程 I/O 点位的数据采集、刷新和同步，使主控制器能够集中管理分布在不同区域的设备。
二、核心功能
通过远程 I/O 通道实现主站与远程机架之间的数据交换。
管理数字量与模拟量输入输出点的数据刷新。
具备基本的通信诊断能力，可监测远程链路状态。
可同时处理来自多个远程站点的 I/O 数据，适用于扩展型自动化系统。
内置字符通信能力，可与简单 ASCII 设备交互（视配置而定）。
三、产品特点
通信稳定：专为工业现场的远程 I/O 通信设计，抗干扰性能强。
响应快速：能够及时更新远程点位，支持较大规模 I/O 系统。
模块化设计：与 Modicon 800 系列机架兼容，安装维护方便。
扩展灵活：适合需要远距离布置 I/O 点位的场景，降低布线难度。
工业级可靠性：支持连续运行，对现场温度、湿度和震动有较强耐受性。
四、典型应用
分散式设备控制系统。
远程机柜布置的自动化生产线。
电力、化工、机械装备等需要跨区域布线的工程现场。
老旧控制系统扩容或分布式改造项目。
需要把大量 I/O 放在远离主机位置的工业现场。
五、使用注意事项
远程通信电缆质量与布线方式对通信稳定性影响明显，应保证线路良好。
与主 CPU 的兼容性需确认，确保主站支持远程 I/O 通信。
远程机架电源必须稳定，以保证数据刷新正常进行。
若有 ASCII 外设接入，需注意通信参数设置一致。
AEG MODICON AS-J892-101远程 I/O 处理器 英文介绍
AEG Modicon AS-J892-101 Remote I/O Processor
Product Description
1、 Product positioning
AS-J892-101 is a remote I/O communication processing module in the Modicon 800 series, used to establish a stable data transmission channel between the main controller and the remote rack. It is mainly responsible for data collection, refreshing, and synchronization of remote I/O points, enabling the main controller to centrally manage devices distributed in different regions.
2、 Core functions
Realize data exchange between the main station and remote racks through remote I/O channels.
Manage the data refresh of digital and analog input/output points.
Have basic communication diagnostic capabilities and can monitor the status of remote links.
Can simultaneously process I/O data from multiple remote sites, suitable for extended automation systems.
Built in character communication capability, capable of interacting with simple ASCII devices (depending on configuration).
3、 Product Features
Communication Stability: Designed specifically for remote I/O communication in industrial sites, with strong anti-interference performance.
Fast response: able to update remote points in a timely manner and support larger scale I/O systems.
Modular design: Compatible with Modicon 800 series racks, easy to install and maintain.
Flexible expansion: Suitable for scenarios that require remote placement of I/O points, reducing wiring difficulty.
Industrial grade reliability: Supports continuous operation and has strong tolerance to on-site temperature, humidity, and vibration.
4、 Typical applications
Distributed equipment control system.
Automated production line with remote cabinet layout.
Engineering sites that require cross regional wiring for power, chemical, mechanical equipment, etc.
Expansion or distributed transformation projects for old control systems.
A large amount of I/O needs to be placed in industrial sites far away from the host location.
5、 Precautions for use
The quality and wiring method of remote communication cables have a significant impact on communication stability, and the line should be ensured to be in good condition.
Compatibility with the main CPU needs to be confirmed to ensure that the main station supports remote I/O communication.
The remote rack power supply must be stable to ensure normal data refresh.
If ASCII peripherals are connected, it is important to ensure consistent communication parameter settings.
AEG MODICON AS-J892-101远程 I/O 处理器 产品展示
