AEG MODICON 170BDM34600输入/输出模块 PDF资料
1.产 品 资 料 介 绍：
AEG Modicon 170BDM34600 输入/输出模块——模块说明
170BDM34600 属于 AEG/Modicon 分布式 I/O 系列中的复合型模块，它把输入与输出功能整合在同一单元中，可同时采集现场信号并驱动执行器。它的设计核心在于“紧凑、稳定、高兼容性”，常被用于空间有限或对布线简化有要求的系统中。
模块核心职能
1. 同步处理输入与输出信号
模块同时具备数字输入通道与数字输出通道，既能接收现场状态，也能直接对设备发出动作指令，是典型的双向控制单元。
2. 作为现场设备与控制器之间的接口
通过系统总线与 PLC 主站通信，实时传输输入数据并接收控制指令，实现完整的信号链路闭环。
3. 支撑分布式控制架构
常用于远程 I/O 站或模块化设备上，使控制系统能覆盖更大的现场范围而不需要长距离布线。
模块特点（加强版）
1. 输入/输出一体化设计
减少模块数量，降低机柜占用空间，布线更紧凑，更适合小型或密集型控制柜。
2. 通道隔离保护
I/O 通道通常具备电气隔离，有效减少干扰和回路冲击造成的损坏风险。
3. 相应速度稳定
输入采样与输出刷新节奏一致，能满足同步动作需求，适用于节拍控制或联锁系统。
4. 工业级抗干扰能力
适用于高电磁噪声、振动等恶劣现场环境，确保信号稳定、动作可靠。
5. 状态指示清晰
模块通常自带 LED 指示，可快速判断每个 I/O 点的实时状态，方便调试与查错。
6. 易于扩展与组合
属于 Modicon 分布式 I/O 系统，可与各类 CPU、通信模块、扩展机架灵活组合。
7. 长周期运行可靠
适应连续运行的应用场景，维护频率低，是很多工厂稳定运行的“基础单元”。
AEG MODICON 170BDM34600输入/输出模块 英文介绍
AEG Modicon 170BDM34600 Input/Output Module - Module Description
The 170BDM34600 is a composite module in the AEG/Modicon distributed I/O series, which integrates input and output functions into the same unit and can simultaneously collect field signals and drive actuators. Its design core lies in "compactness, stability, and high compatibility", often used in systems with limited space or requirements for simplified wiring.
Core functions of the module
1. Synchronize the processing of input and output signals
The module has both digital input channels and digital output channels, which can receive on-site status and directly issue action commands to the equipment. It is a typical bidirectional control unit.
2. As an interface between on-site equipment and controllers
By communicating with the PLC master station through the system bus, real-time input data is transmitted and control instructions are received, achieving a complete closed-loop signal link.
3. Support distributed control architecture
Commonly used on remote I/O stations or modular devices to enable control systems to cover a larger field area without the need for long-distance wiring.
Module Features (Enhanced Version)
1. Integrated input/output design
Reduce the number of modules, reduce the space occupied by cabinets, make wiring more compact, and be more suitable for small or dense control cabinets.
2. Channel isolation protection
I/O channels typically have electrical isolation to effectively reduce the risk of damage caused by interference and circuit surges.
3. Corresponding speed stability
The input sampling and output refresh rhythm are consistent, which can meet the synchronous action requirements and is suitable for beat control or interlocking systems.
4. Industrial grade anti-interference capability
Suitable for harsh on-site environments such as high electromagnetic noise and vibration, ensuring stable signals and reliable actions.
5. Clear status indication
Modules usually come with LED indicators, which can quickly determine the real-time status of each I/O point, facilitating debugging and error checking.
6. Easy to expand and combine
Belonging to Modicon distributed I/O system, it can be flexibly combined with various CPUs, communication modules, and expansion racks.
7. Long term reliable operation
Adapting to continuous operation application scenarios with low maintenance frequency, it is the "basic unit" for stable operation of many factories.
AEG MODICON 170BDM34600输入/输出模块 产品展示
