AEG MODICON PC-M984-230可编程控制器 PDF资料
1.产 品 资 料 介 绍：
AEG Modicon PC-M984-230 可编程控制器——系统级核心单元说明
PC-M984-230 是 Modicon 984 系列中的典型主控 CPU 机型，属于那个时代“性能强、兼容性好、能长期跑”的工业级 PLC。它的定位不是小型控制器，而是用于完整生产线或大型设备的中央逻辑处理单元，可靠性和可扩展性是它的核心优势。
模块定位与功能概述
这款控制器负责整个系统的决策和运算任务，包括：
执行逻辑程序与顺控流程
从常规逻辑运算到复杂时序管理，都由它统一处理。协调所有背板与远程 I/O
能管理大量 I/O 模块，是中大型控制架构的“主协调器”。处理通信与数据交换
支持 984 系列常用通信方式，用于与上位机或其他 PLC 互联。系统诊断与状态管理
实时监测机架状态、模块健康状况和运行数据。
特点深入解析（扩展版）
1. 强大的指令集，适用于复杂自动化流程
984 系列以丰富的逻辑、数学、定时、计数与数据操作指令著称，可应对流程工业、机械自动化等要求较高的控制任务。
2. 稳定的扫描周期
运行节奏稳定，适合对动作一致性要求高的场合，例如顺控、电机联锁控制、工艺互锁等。
3. 高兼容性的 984 架构
PC-M984-230 能与多种 I/O、通信模块、扩展机架搭配，让系统结构可随工艺扩大。
4. 工业级耐用设计
适用高温、粉尘、电磁干扰环境，非常典型的“装上就能跑十几年”的工业控制器。
5. 程序保存能力强
带有断电保持机制，程序与关键参数在长时间停电情况下仍能保留。
6. 维护方便
模块化结构，CPU 更换、扩展、调试都不繁琐，老工程师非常熟悉的一类结构。
7. 适合中大型系统架构
尤其适用于设备较多、信号量大的工厂生产线。
AEG MODICON PC-M984-230可编程控制器 英文介绍
AEG Modicon PC-M984-230 Programmable Controller - System Level Core Unit Description
PC-M984-230 is a typical main control CPU model in the Modicon 984 series, belonging to the industrial grade PLC of that era with "strong performance, good compatibility, and long-term operation". Its positioning is not as a small controller, but as a central logic processing unit for complete production lines or large equipment, with reliability and scalability being its core advantages.
Module positioning and functional overview
This controller is responsible for the decision-making and computational tasks of the entire system, including:
Execute logical programs and sequential control processes
It handles everything from conventional logical operations to complex timing management uniformly.
Coordinate all backboards and remote I/O
Capable of managing a large number of I/O modules, it is the "main coordinator" for medium to large control architectures.
Handling communication and data exchange
Support 984 series commonly used communication methods for interconnection with upper computers or other PLCs.
System diagnosis and status management
Real time monitoring of rack status, module health, and operational data.
In depth Analysis of Characteristics (Extended Version)
1. Powerful instruction set suitable for complex automation processes
The 984 series is known for its rich logic, mathematics, timing, counting, and data operation instructions, which can meet the high requirements of control tasks such as process industry and mechanical automation.
2. Stable scanning cycle
Stable operating rhythm, suitable for occasions with high requirements for action consistency, such as sequential control, motor interlocking control, process interlocking, etc.
3. High compatibility 984 architecture
PC-M984-230 can be paired with various I/O, communication modules, and expansion racks, allowing the system structure to expand with the process.
4. Industrial grade durable design
Suitable for high temperature, dust, and electromagnetic interference environments, it is a very typical industrial controller that can run for more than ten years when installed.
5. Strong program saving ability
Equipped with a power-off hold mechanism, the program and key parameters can still be retained during prolonged power outages.
6. Easy maintenance
Modular structure, with easy CPU replacement, expansion, and debugging, is a type of structure that experienced engineers are very familiar with.
7. Suitable for medium to large system architectures
Especially suitable for factory production lines with a large number of devices and high signal volume.
AEG MODICON PC-M984-230可编程控制器 产品展示
