AEG MODICON 110CPU61200微型CPU直流电模块 PDF资料
1.产 品 资 料 介 绍：
AEG Modicon 110CPU61200 微型 CPU 直流电模块——功能与特点说明
110CPU61200 属于 AEG/Modicon 小型 PLC 系列中的核心处理单元，它把“微型结构”与“工业级可靠性”结合在一起，适用于空间紧凑但要求稳定控制的场景。该 CPU 自带直流电源输入设计，使其能直接使用 24VDC 供电，方便在标准工业控制柜中部署。
模块定位与系统作用
作为整套微型 PLC 的中央处理器
负责运行用户逻辑、完成扫描周期、执行条件判断、处理时序与计数逻辑。管理本地与扩展 I/O
通过内置 I/O 或扩展模块实现对现场设备的输入和输出控制。保持系统稳定运行
负责内部数据处理、诊断、错误检测与操作状态管理，是整个控制单元的核心。
特点详述（扩展版）
1. 直流供电更适合工业现场
使用 24VDC 输入，配合标准电源系统与常见电控柜更兼容，减少交流电噪声造成的干扰。
2. 微型结构但处理能力扎实
虽然属于小型 PLC，但具备完整的逻辑指令、定时器、计数器、顺控、内部寄存器等功能，适合中小型设备的主控需求。
3. 稳定的扫描机制
具备固定或自适应扫描周期，能够保证动作逻辑一致，适合高稳定和连续运行的应用。
4. 内置系统诊断能力
能够检测通信异常、I/O 故障、供电问题等，让维护人员能更快判断故障来源。
5. 可靠的存储机制
具备掉电保持功能，断电后程序和关键数据不会丢失，适合设备长周期运行。
6. 良好的可扩展性
可搭配多种 Modicon 扩展模块（I/O、通信、电源），让系统规模可根据需要灵活扩大。
7. 工业环境适应能力强
抗干扰、防振动、耐温变化的性能满足了工厂、电站、机床等典型工业场景的要求。
AEG MODICON 110CPU61200微型CPU直流电模块 英文介绍
AEG Modicon 110CPU61200 Micro CPU DC Module - Function and Feature Description
The 110CPU61200 belongs to the core processing unit of the AEG/Modicon small PLC series, which combines "microstructure" with "industrial grade reliability" and is suitable for scenarios with compact space but stable control requirements. The CPU comes with a DC power input design, allowing it to directly use 24VDC power supply, making it easy to deploy in standard industrial control cabinets.
Module positioning and system function
As the central processing unit of the entire micro PLC system
Responsible for running user logic, completing scan cycles, determining execution conditions, processing timing and counting logic.
Manage local and extended I/O
Implement input and output control of field devices through built-in I/O or expansion modules.
Maintain stable system operation
Responsible for internal data processing, diagnosis, error detection, and operational status management, it is the core of the entire control unit.
Feature Description (Extended Version)
1. DC power supply is more suitable for industrial sites
Using 24VDC input, it is more compatible with standard power systems and common electrical control cabinets, reducing interference caused by AC noise.
2. Micro structured but with solid processing capabilities
Although it belongs to a small PLC, it has complete functions such as logic instructions, timers, counters, sequential control, internal registers, etc., which are suitable for the main control needs of small and medium-sized equipment.
3. Stable scanning mechanism
Equipped with fixed or adaptive scanning cycles, it can ensure consistent action logic and is suitable for applications with high stability and continuous operation.
4. Built in system diagnostic capability
Being able to detect communication anomalies, I/O failures, power supply issues, etc., enables maintenance personnel to quickly identify the source of faults.
5. Reliable storage mechanism
Equipped with a power-off hold function, programs and critical data will not be lost after power failure, making it suitable for long-term operation of equipment.
6. Good scalability
It can be paired with various Modicon expansion modules (I/O, communication, power), allowing the system scale to be flexibly expanded according to needs.
7. Strong adaptability to industrial environments
The performance of anti-interference, anti vibration, and temperature resistance meets the requirements of typical industrial scenarios such as factories, power stations, and machine tools.
AEG MODICON 110CPU61200微型CPU直流电模块 产品展示
