GIDINGS&LEWIS 503-70075-00视频内存组装板 PDF资料

1.产 品 资 料 介 绍：

Giddings & Lewis 503-70075-00 视频内存组装板

产品概述

503-70075-00 是 Giddings & Lewis 工业控制系统中的 视频内存组装板，主要用于数控系统或工业监控设备中提供图像数据缓存和处理支持。该模块可对控制器传输的图像或显示信息进行暂存和管理，保障人机界面（HMI）或图形显示系统的稳定运行。

产品特点

1. 高性能缓存

• 提供快速视频数据读写能力，支持复杂图形和实时显示

• 增强显示响应速度，避免画面延迟

2. 工业级可靠性

• 采用耐高温、抗振动元件，适应严苛工业环境

• 支持长时间连续运行

3. 兼容性强

• 与 Giddings & Lewis 控制器及图形显示模块无缝集成

• 可支持多种显示分辨率和图形界面

4. 模块化设计

• 插卡式结构，便于系统升级和维护

• 可单独更换或扩展

5. 数据保护与稳定性

• 内置信号完整性设计，保证视频数据传输稳定

• 防干扰和短路保护，提高系统安全性

应用场景

• CNC 数控机床：为图形操作面板和显示界面提供视频缓存支持

• 工业自动化生产线：支持监控系统的视频数据处理与显示

• 人机界面（HMI）系统：确保图形界面流畅显示和实时响应

• 设备升级与维护：可作为现有控制系统的显示性能增强模块

英文资料：

Giddings&Lewis 503-70075-00 Video Memory Assembly Board

Product Overview

503-70075-00 is a video memory assembly board in Giddings&Lewis industrial control systems, mainly used to provide image data caching and processing support in CNC systems or industrial monitoring equipment. This module can temporarily store and manage the images or display information transmitted by the controller, ensuring the stable operation of the human-machine interface (HMI) or graphic display system.

Product Features

High performance cache

Provide fast video data reading and writing capabilities, support complex graphics and real-time display

Enhance display response speed and avoid screen delay

Industrial grade reliability

Adopting high-temperature and vibration resistant components to adapt to harsh industrial environments

Support long-term continuous operation

Strong compatibility

Seamless integration with Giddings&Lewis controllers and graphics display modules

Supports multiple display resolutions and graphical interfaces

modular design

Plug in card structure, convenient for system upgrade and maintenance

Can be replaced or expanded separately

Data Protection and Stability

Built in signal integrity design ensures stable video data transmission

Anti interference and short circuit protection to improve system safety

Application scenarios

CNC machine tools: provide video caching support for graphic operation panels and display interfaces

Industrial automation production line: supports video data processing and display of monitoring systems

Human Machine Interface (HMI) System: Ensure smooth display and real-time response of graphical interfaces

Equipment upgrade and maintenance: can serve as a display performance enhancement module for existing control systems
