AMAT Applied Materials 0190-09272定向耦合器 PDF资料

1.产 品 资 料 介 绍：

AMAT Applied Materials 0190-09272 定向耦合器 产品特点

一、产品概述
AMAT 0190-09272 定向耦合器是一种高功率射频分配组件，常用于等离子体、蚀刻或沉积系统中的射频能量传输路径，用于监测和反馈功率信号。其设计重点是高方向性、低损耗与高可靠性。

二、主要特点

1. 高功率承载能力
    额定功率约 1500 W，满足半导体设备射频系统的大功率输出需求。

2. 高方向性
    具备良好的正向与反向信号区分能力，可实现精确的功率监测与反射检测。

3. 低插入损耗
    对主传输信号的损耗极小，确保系统能量传输效率高。

4. 良好隔离性能
    有效减少主路与耦合支路之间的串扰，保证测量精度。

5. 稳定可靠的结构设计
    采用金属封装和精密机械接口，具备良好的机械强度和耐用性，适应高温与高频工作环境。

6. 匹配性优异
    驻波比（VSWR）低，保证射频系统匹配性能优良，减少反射功率。

7. 维护方便
    模块化结构便于更换与维护，常作为射频链路中的可拆装元件。

AMAT Applied Materials 0190-09272定向耦合器 英文介绍

AMAT Applied Materials 0190-09272 Directional Coupling Product Features

1、 Product Overview

AMAT 0190-09272 directional coupler is a high-power RF distribution component commonly used in RF energy transmission paths in plasma, etching, or deposition systems for monitoring and feedback of power signals. Its design focuses on high directionality, low loss, and high reliability.

2、 Main features

High power carrying capacity

The rated power is about 1500 W, which meets the high-power output requirements of semiconductor equipment RF systems.

High directionality

Having good ability to distinguish between forward and reverse signals, it can achieve accurate power monitoring and reflection detection.

Low insertion loss

The loss of the main transmission signal is minimal, ensuring high energy transmission efficiency of the system.

Good isolation performance

Effectively reduce crosstalk between the main circuit and the coupling branch, ensuring measurement accuracy.

Stable and reliable structural design

Adopting metal packaging and precision mechanical interfaces, it has good mechanical strength and durability, and is suitable for high temperature and high frequency working environments.

Excellent compatibility

Low standing wave ratio (VSWR) ensures excellent matching performance of the RF system and reduces reflected power.

easy maintenance

The modular structure is easy to replace and maintain, and is often used as a detachable component in RF links.
