ICS TRIPLEX T9402冗余控制模块，T9402使用指导

内存配置默认值。动态RAM夹层板的默认配置将使用从使用ENV参数“的基址”选择的地址开始的最大内存大小动态内存”。基址参数默认为0。较小的夹层将紧跟在内存映射中较大的上方。如果相同尺寸和类型的夹层存在时，第一个（最靠近电路板）映射到选定的基址。如果夹层存在相同大小但不同类型（奇偶校验和ECC），奇偶校验类型将映射到随后是选定的基址和ECC类型的夹层。

ICS TRIPLEX T9402冗余控制模块SRAM不默认为内存映射中与动态RAMENV相邻的位置询问以下一系列问题，以设置MVME172的VMEbus接口系列模块。您应该具备VMEchip2的工作知识，如MVME172 VME嵌入式控制器程序员参考指南配置本系列还包括设置ROM和闪存访问时间的问题从属地址解码器用于允许另一个VMEbus主机访问的本地资源MVME172LX。设置了两个从地址解码器。它们的设置如下：配置IndustryPackENV提出了以下一系列问题来设置IndustryPack模块（IPs）在MVME172LXs上。MVME172 VME嵌入式控制器程序员参考指南介绍了基址和IP寄存器设置。提到该手册提供了有关设置基址和寄存器位的信息。介绍本章介绍了MVME172LX VME嵌入式控制器方框图级别。功能描述概述了MVME172LX，然后详细描述了电路。图4-1显示了整个电路板的框图建筑学其他MVME172LX区块的详细说明，包括ASIC和外围芯片中的可编程寄存器可在MVME172嵌入式控制器程序员参考指南（零件号VME172A/PG）。有关的功能说明，请参阅MVME172LX更深入。

Memory Configuration Defaults.

The default configuration for Dynamic RAM mezzanine boards will position the mezzanine with

the largest memory size to start at the address selected with the ENV parameter "Base Address of

Dynamic Memory". The Base Address parameter defaults to 0. The smaller sized mezzanine will

follow immediately above the larger in the memory map. If mezzanines of the same size and type

are present, the first (closest to the board) is mapped to the selected base address. If mezzanines of

the same size but different type (parity and ECC) are present, the parity type will be mapped to the

selected base address and the ECC type mezzanine will follow. The SRAM does not default to a

location in the memory map that is contiguous with Dynamic RAMENV asks the following series of questions to set up the VMEbus interface for the MVME172

series modules. You should have a working knowledge of the VMEchip2 as given in the

MVME172 VME Embedded Controller Programmer’s Reference Guide in order to perform this

configuration. Also included in this series are questions for setting ROM and Flash access time.

The slave address decoders are used to allow another VMEbus master to access a local resource of

the MVME172LX. There are two slave address decoders set. They are set up as follows:Configuring the IndustryPacks

ENV asks the following series of questions to set up IndustryPack modules

(IPs) on MVME172LXs.

The MVME172 VME Embedded Controller Programmer’s Reference

Guide describes the base addresses and the IP register settings. Refer to

that manual for information on setting base addresses and register bits. Introduction

This chapter describes the MVME172LX VME embedded controller on a

block diagram level. The Description of Features provides an overview of

the MVME172LX, followed by a detailed description of several blocks of

circuitry. Figure 4-1 shows a block diagram of the overall board

architecture.

Detailed descriptions of other MVME172LX blocks, including

programmable registers in the ASICs and peripheral chips, can be found in

the MVME172 Embedded Controller Programmer’s Reference Guide

(part number VME172A/PG). Refer to it for a functional description of the

MVME172LX in greater depth.
