SANYO DENKI 0610100714-E示教器 PDF资料
1.产 品 资 料 介 绍：
一、产品概述
该型号为 SANYO DENKI 提供的示教器（也称为手持操作面板、Teach pendant），用于机器或伺服系统的人机交互界面。示教器通常用于手动操作、点位教学、运动设置、调试参数等。
二、主要功能与特点
人机界面：配备显示屏、导航按键或触控操作，方便操作人员进行点位教学、轨迹设定或手动控制。
手持便携：便于操作者在设备周围移动操作，适合调试、监控、编程使用。
与伺服系统配合：可连接伺服驱动器或控制器，用于控制机床、机器人或自动化装置的运动。
安全功能：通常包括操作锁定、急停按钮、电缆／无线传输接口等，以确保现场操作安全。
定制/兼容性：可能为特定设备或控制系统专用款，需要与对应型号的驱动器或控制器匹配使用。
三、选型与使用注意事项
接口兼容性：确保该示教器所连接的控制器或伺服系统支持其接口类型、协议或连接方式。
功能匹配：确认示教器支持所需的操作功能（如点定位、轨迹设定、手动移动、调试模式等）。
环境条件：安装使用时应考虑操作环境（如温度、湿度、灰尘、振动等）是否适合该设备。
安全要求：使用时应确保急停、安全联锁、操作权限分配等安全机制齐备。
备件与维修：示教器属于操作界面关键设备，应留意维修、更换面板、按键、电缆等备件情况。
SANYO DENKI 0610100714-E示教器 英文介绍
1、 Product Overview
This model is a teaching pendant (also known as a handheld control panel or Teach pendant) provided by SANYO DENKI, used for human-machine interaction interfaces of machines or servo systems. Teaching pendant is usually used for manual operation, point teaching, motion setting, parameter debugging, etc.
2、 Main functions and features
Human machine interface: equipped with a display screen, navigation buttons or touch controls, convenient for operators to perform point teaching, trajectory setting or manual control.
Handheld and portable: convenient for operators to move and operate around the device, suitable for debugging, monitoring, and programming.
Cooperate with servo system: It can be connected to servo drives or controllers to control the movement of machine tools, robots, or automation devices.
Safety functions: usually include operation locking, emergency stop button, cable/wireless transmission interface, etc., to ensure on-site operation safety.
Customization/Compatibility: It may be specific to a particular device or control system and needs to be matched with the corresponding model of driver or controller for use.
3、 Selection and usage precautions
Interface compatibility: Ensure that the controller or servo system connected to the teaching pendant supports its interface type, protocol, or connection method.
Function matching: Confirm that the teaching pendant supports the required operational functions (such as point positioning, trajectory setting, manual movement, debugging mode, etc.).
Environmental conditions: When installing and using, consideration should be given to whether the operating environment (such as temperature, humidity, dust, vibration, etc.) is suitable for the equipment.
Safety requirements: When using, ensure that safety mechanisms such as emergency stop, safety interlock, and operation permission allocation are complete.
Spare parts and maintenance: The teaching pendant is a key equipment in the operation interface, and attention should be paid to the maintenance, replacement of panels, buttons, cables, and other spare parts.
SANYO DENKI 0610100714-E示教器 产品展示
