SANYO DENKI Q2AA10150HXSH交流伺服电机 PDF资料
1.产 品 资 料 介 绍：
一、产品概述
SANYO DENKI Q2AA10150HXSH 是 SANMOTION Q 系列中惯量型 AC 伺服电机，额定功率约为 1.5 kW，适用于要求平稳驱动、精确定位及高可靠性的工业自动化场合。该系列产品在保持高响应性能的同时，兼顾负载惯量匹配能力与运行稳定性。
二、主要技术参数（典型值）
系列类型：SANMOTION Q 系列（中惯量型）
额定功率：1.5 kW
额定电压：AC 200 V
额定扭矩：约 7.5 N·m
最高转速：约 3000 r/min
法兰尺寸：130 mm
惯量类别：中惯量设计
制动器：无制动（型号中 “X” 代表无制动）
冷却方式：自然风冷
反馈装置：内置高分辨率增量式编码器
结构形式：封闭式外壳，防尘防油密封结构
三、产品特点
中惯量设计，平稳运行
相比低惯量电机，更能抑制负载变化带来的转速波动，适合中负载、高稳定性工况。高精度控制性能
搭载高分辨率编码器，保证了优异的定位精度与速度响应性能。扭矩输出平稳、噪音低
优化的电磁设计显著降低转矩波动与振动，使运行更顺畅安静。效率高、温升低
采用高效线圈与低损耗铁芯材料，长时间运行时温升小，能量利用率高。坚固可靠的结构
电机壳体采用全封闭结构，并配有防尘、防油密封圈，适应多种工业环境。安装与维护方便
法兰、轴尺寸标准化，可与同系列及上一代型号互换，便于设备更新或备件更换。
四、典型应用领域
数控机床进给及主轴驱动
自动化生产线驱动系统
搬运与包装机械
机器人关节及旋转平台
印刷、纺织与电子组装设备
SANYO DENKI Q2AA10150HXSH交流伺服电机 英文介绍
1、 Product Overview
SANYO DENKI Q2AA10150HXSH is an inertia type AC servo motor in the SANMOTION Q series, with a rated power of approximately 1.5 kW, suitable for industrial automation applications that require smooth driving, precise positioning, and high reliability. This series of products balances load inertia matching capability and operational stability while maintaining high response performance.
2、 Main technical parameters (typical values)
Series type: SANMOTION Q series (medium inertia type)
Rated power: 1.5 kW
Rated voltage: AC 200 V
Rated torque: approximately 7.5 N · m
Maximum speed: about 3000 r/min
Flange size: 130 mm
Inertia category: Medium inertia design
Brake: No brake ("X" in the model represents no brake)
Cooling method: natural air cooling
Feedback device: Built in high-resolution incremental encoder
Structural form: Closed shell, dust-proof and oil proof sealing structure
3、 Product Features
Medium inertia design for smooth operation
Compared to low inertia motors, it can better suppress speed fluctuations caused by load changes and is suitable for medium load and high stability working conditions.
High precision control performance
Equipped with a high-resolution encoder, it ensures excellent positioning accuracy and speed response performance.
Smooth torque output and low noise
The optimized electromagnetic design significantly reduces torque fluctuations and vibrations, making operation smoother and quieter.
High efficiency, low temperature rise
Using efficient coils and low loss iron core materials, the temperature rise is small and the energy utilization rate is high during long-term operation.
Durable and reliable structure
The motor housing adopts a fully enclosed structure and is equipped with dust-proof and oil proof sealing rings, suitable for various industrial environments.
Easy installation and maintenance
Standardization of flange and shaft dimensions, interchangeable with the same series and previous generation models, facilitating equipment updates or spare parts replacement.
4、 Typical application areas
CNC machine tool feed and spindle drive
Automated production line drive system
Handling and packaging machinery
Robot joints and rotating platform
Printing, textile, and electronic assembly equipment
SANYO DENKI Q2AA10150HXSH交流伺服电机 产品展示
