SANYO DENKI P10B13150HXSA5 伺服发动机 PDF资料
1.产 品 资 料 介 绍：
一、产品简介
SANYO DENKI P10B13150HXSA5 属于 SANMOTION P 系列中惯量型 AC 伺服电机，额定功率约 1.5 kW，设计注重高精度定位与平稳运行性能，广泛应用于中型自动化机械、数控设备及工业驱动系统中。
二、主要技术参数（典型规格）
系列：SANMOTION P 系列
类型：中惯量伺服电机
额定功率：1.5 kW
额定电压：AC 200 V
额定扭矩：约 7.2 N·m
最高转速：3000 r/min
法兰尺寸：130 mm 方形法兰
制动器：无制动（型号中 “X” 表示无制动器）
反馈装置：内置高分辨率增量编码器
冷却方式：自然风冷
结构：封闭式外壳，具防尘防油密封
三、产品特点
高精度控制
配备高分辨率编码器，定位响应迅速，位置控制精度高，适合精密加工与同步驱动场合。中惯量设计，运行稳定
通过优化转子惯量分布，使电机在负载变化时仍能保持平稳运行，减少振动与抖动。高效率、低发热
电磁结构优化，铜损与铁损低，连续运行时温升较小，适用于长时间作业系统。优良的动态响应性能
起动与停止时间短，惯量与转矩平衡良好，可满足中速高频启停的控制需求。结构坚固、可靠性高
采用全封闭外壳设计，具良好防尘、防油特性，可在一般工业环境下稳定运行。安装兼容性强
与同功率等级的 SANMOTION Q 系列在安装尺寸上兼容，便于设备升级与替换。
SANYO DENKI P10B13150HXSA5 伺服发动机 英文介绍
1、 Product Introduction
SANYO DENKI P10B13150HXSA5 belongs to the SANMOTION P series inertia type AC servo motor, with a rated power of about 1.5 kW. The design focuses on high-precision positioning and smooth operation performance, and is widely used in medium-sized automation machinery, CNC equipment, and industrial drive systems.
2、 Main technical parameters (typical specifications)
Series: SANMOTION P Series
Type: Medium inertia servo motor
Rated power: 1.5 kW
Rated voltage: AC 200 V
Rated torque: approximately 7.2 N · m
Maximum speed: 3000 r/min
Flange size: 130mm square flange
Brake: No brake ("X" in the model indicates no brake)
Feedback device: Built in high-resolution incremental encoder
Cooling method: natural air cooling
Structure: Closed shell with dust-proof and oil proof seal
3、 Product Features
high-precision control
Equipped with a high-resolution encoder, the positioning response is fast and the position control accuracy is high, suitable for precision machining and synchronous driving occasions.
Medium inertia design, stable operation
By optimizing the distribution of rotor inertia, the motor can maintain smooth operation even when the load changes, reducing vibration and jitter.
High efficiency, low heat generation
Electromagnetic structure optimization, low copper and iron losses, minimal temperature rise during continuous operation, suitable for long-term operating systems.
Excellent dynamic response performance
Short start and stop time, good balance between inertia and torque, can meet the control requirements of medium speed and high-frequency start and stop.
Sturdy structure and high reliability
Adopting a fully enclosed shell design, it has good dust and oil resistance characteristics and can operate stably in general industrial environments.
Strong installation compatibility
Compatible with SANMOTION Q series of the same power level in terms of installation size, making it easy to upgrade and replace equipment.
SANYO DENKI P10B13150HXSA5 伺服发动机 产品展示
