SANYO DENKI Q2AA08100DXS2交流电伺服电机 PDF资料
1.产 品 资 料 介 绍：
产品概述
Q2AA08100DXS2 属于 SANYO DENKI Q 系列交流伺服电机，是一款中功率、高响应、高精度电机，适用于各种工业自动化设备和运动控制系统。该系列强调紧凑体积、可靠性和快速响应性能。
主要特点
高响应性能
低惯量转子设计，能快速响应控制信号，适合高动态负载和频繁启停场景。精密定位
配备高分辨率编码器，实现位置、速度及扭矩闭环控制，高重复定位精度。稳定输出
在额定转速范围内提供平稳、连续的扭矩输出，负载波动对运行影响小。高效率与低发热
优化绕组和磁路设计，提高能量转换效率，降低温升，延长电机寿命。低振动与低噪音
高刚性结构与精密平衡转子，确保电机运行平稳，噪音低。兼容性强
可与 Q 系列伺服驱动器配合使用，支持速度、位置及扭矩控制模式。
典型应用领域
数控机床进给轴或中速轴驱动
自动化装配线和传动系统
机器人关节轴或多轴运动系统
包装、印刷机械中的送料、对位和张力控制
精密检测、扫描和测量设备
SANYO DENKI Q2AA08100DXS2交流电伺服电机 英文介绍
Product Overview
Q2AA08100DXS2 belongs to the SANYO DENKI Q series AC servo motor, which is a medium power, high response, high-precision motor suitable for various industrial automation equipment and motion control systems. This series emphasizes compact size, reliability, and fast response performance.
Main Features
High responsiveness performance
Low inertia rotor design, capable of quickly responding to control signals, suitable for high dynamic loads and frequent start stop scenarios.
precision positioning
Equipped with a high-resolution encoder to achieve closed-loop control of position, speed, and torque, with high repeatability positioning accuracy.
stable output
Provide smooth and continuous torque output within the rated speed range, with minimal impact of load fluctuations on operation.
High efficiency and low heat generation
Optimize winding and magnetic circuit design, improve energy conversion efficiency, reduce temperature rise, and extend motor life.
Low vibration and low noise
High rigidity structure and precision balanced rotor ensure smooth operation and low noise of the motor.
Strong compatibility
Can be used in conjunction with Q series servo drives, supporting speed, position, and torque control modes.
Typical application areas
CNC machine tool feed axis or medium speed axis drive
Automated assembly line and transmission system
Robot joint axis or multi axis motion system
Feeding, alignment, and tension control in packaging and printing machinery
Precision testing, scanning, and measuring equipment
SANYO DENKI Q2AA08100DXS2交流电伺服电机 产品展示
