SANYO DENKI P10B10075HBS20交流伺服电机 PDF资料
1.产 品 资 料 介 绍：
一、产品概述
该型号为 0.75 kW 等级伺服电机，额定电压 200–240 V，额定转速 3000 rpm，带有保持制动器（Holding Brake），适用于需要中小功率、高精度控制的自动化设备。
二、主要产品特点
高响应性能
采用优化的低惯量转子与稀土永磁材料，实现快速加减速反应，适合高动态控制系统。高精度定位
配备高分辨率增量型编码器，确保速度与位置反馈精确可靠，定位重复性出色。输出稳定
在额定转速范围内保持平稳的扭矩输出，即使低速运行也能保持稳定驱动。结构紧凑轻量
法兰尺寸约 100 mm，体积小、安装灵活，便于集成到各种机械设备。带制动器设计
内置直流保持制动器，保证停机时轴位置锁定，提高系统安全性与精度保持。高可靠性
具备过电流、过温、过压等多重保护设计，可在长期连续运行中保持稳定性能。高效率低发热
优化绕组结构与散热通道，能有效降低温升，延长电机寿命。
三、典型应用领域
数控机床进给轴与主轴控制
实现高精度、高速度的刀具进给与定位。工业机器人关节驱动
用于中等负载轴的运动控制，响应快，定位精确。电子装配与贴片设备
满足微小位移、高速定位和同步控制的需求。包装、印刷机械
用于送料、切割、张力控制等环节，运行平稳。自动化生产线
驱动传送、分拣、升降等机构，保障节拍一致与控制精度。检测与测量设备
应用于光学检测、坐标测量等精密运动场合。
SANYO DENKI P10B10075HBS20交流伺服电机 英文介绍
1、 Product Overview
This model is a 0.75 kW servo motor with a rated voltage of 200-240 V and a rated speed of 3000 rpm. It is equipped with a holding brake and is suitable for automation equipment that requires small to medium power and high-precision control.
2、 Main product features
High responsiveness performance
Adopting optimized low inertia rotors and rare earth permanent magnet materials to achieve rapid acceleration and deceleration reactions, suitable for high dynamic control systems.
high-precision positioning
Equipped with a high-resolution incremental encoder, ensuring accurate and reliable speed and position feedback, and excellent positioning repeatability.
Stable output
Maintain stable torque output within the rated speed range, even at low speeds, and maintain stable driving.
Compact and lightweight structure
The flange size is about 100mm, with a small volume and flexible installation, making it easy to integrate into various mechanical equipment.
Design with brake system
Built in DC holding brake ensures shaft position locking during shutdown, improving system safety and accuracy maintenance.
high reliability
Equipped with multiple protection designs such as overcurrent, overtemperature, and overvoltage, it can maintain stable performance during long-term continuous operation.
High efficiency and low heat generation
Optimizing the winding structure and heat dissipation channels can effectively reduce temperature rise and extend the lifespan of the motor.
3、 Typical application areas
CNC machine tool feed axis and spindle control
Realize high-precision and high-speed tool feed and positioning.
Industrial robot joint drive
Used for motion control of medium load axes, with fast response and precise positioning.
Electronic assembly and surface mount equipment
Meet the needs of small displacement, high-speed positioning, and synchronous control.
Packaging and printing machinery
Used for feeding, cutting, tension control and other processes, running smoothly.
automatic production line
Drive transmission, sorting, lifting and other mechanisms to ensure consistent rhythm and control accuracy.
Testing and measuring equipment
Applied to precision motion applications such as optical inspection and coordinate measurement.
SANYO DENKI P10B10075HBS20交流伺服电机 产品展示
