Giddings & Lewis 502-03681-02 输出模块

产品概述

502-03681-02 是 Giddings & Lewis 工业控制与数控系统中的 输出模块。它作为控制器与现场执行装置之间的接口，主要负责将控制器发出的逻辑信号、控制指令转换为实际的驱动信号，控制各种外部设备的运行。

技术特性

• 模块类型：数字量/继电器输出模块

• 功能定位：

• 将控制逻辑转化为电信号输出

• 驱动执行机构（电机、继电器、接触器、指示装置等）

• 具备过载、短路保护，适合工业高可靠性要求

• 接口设计：采用标准化插槽式结构，方便系统集成与扩展

应用领域

1. CNC 数控机床

• 输出控制信号至主轴伺服电机或辅助电机

• 驱动冷却液泵、液压装置、润滑系统等外围设备

2. 自动化生产线

• 控制输送带、气动执行元件、分拣机械手等执行单元

• 作为控制中心与现场设备之间的逻辑输出接口

3. 机器人与运动控制

• 输出动作指令至驱动模块，实现机械臂或平台的同步动作

• 管理运动过程中的启停与切换

4. 工厂过程控制

• 驱动报警灯、蜂鸣器等信号装置

• 启动/停止工艺设备，实现全自动运行

产品优势

• 高可靠性：满足长时间运行的工业需求，抗干扰能力强

• 快速响应：确保控制指令实时传递到执行机构

• 模块化维护：可独立更换或扩展，便于系统升级与维修

• 兼容性好：与 Giddings & Lewis 控制平台无缝集成，支持多种现场设备

英文资料：

Giddings&Lewis 502-03681-02 Output Module

Product Overview

502-03681-02 is an output module in Giddings&Lewis industrial control and numerical control systems. It serves as the interface between the controller and the on-site execution device, mainly responsible for converting the logic signals and control instructions issued by the controller into actual driving signals, and controlling the operation of various external devices.

Technical Characteristics

Module type: digital quantity/relay output module

Functional positioning:

Convert control logic into electrical signal output

Drive actuators (motors, relays, contactors, indicating devices, etc.)

Equipped with overload and short circuit protection, suitable for industrial high reliability requirements

Interface design: Adopting a standardized slot structure for easy system integration and expansion

Application field

CNC machine tool

Output control signal to spindle servo motor or auxiliary motor

Drive peripheral equipment such as coolant pump, hydraulic device, lubrication system, etc

Automatic production line

Control the execution units such as conveyor belts, pneumatic actuators, sorting robots, etc

As the logical output interface between the control center and on-site equipment

Robots and Motion Control

Output action instructions to the drive module to achieve synchronous actions of the robotic arm or platform

Manage the start stop and switching during the movement process

Factory Process Control

Drive signal devices such as alarm lights and buzzers

Start/stop process equipment to achieve fully automatic operation

Product advantages

High reliability: meets the industrial needs of long-term operation, with strong anti-interference ability

Quick response: Ensure real-time transmission of control instructions to the executing mechanism

Modular maintenance: can be independently replaced or expanded, making it easy to upgrade and repair the system

Good compatibility: seamlessly integrated with Giddings&Lewis control platform, supporting multiple on-site devices
