GIDDINGS & LEWIS   M.1302.6214驱动板 PDF资料

1.产 品 资 料 介 绍：

一、产品概述

GIDDINGS & LEWIS M.1302.6214 驱动板是一种用于工业自动化系统的核心电子控制部件，主要应用于伺服系统、运动控制以及数控机床的驱动环节。该驱动板通过精确的信号处理与电流控制，实现对电机的高速响应和稳定运行，是复杂机械设备稳定、高效运行的重要保障。

二、技术参数（典型特性）

• 型号：M.1302.6214

• 功能定位：伺服驱动控制板

• 输入电压：匹配工业电源规格，具备稳定的电源滤波电路

• 输出特性：支持对伺服电机/步进电机的精准驱动

• 控制接口：具备与上位机、PLC 或数控系统的兼容接口

• 信号处理：高速响应电路，减少延迟，提升动态性能

• 保护功能：过流保护、过热保护、短路保护

三、应用场景

1. 数控机床（CNC）：实现精密加工中的伺服驱动与电机控制。

2. 自动化生产线：用于机器人、传送设备等关键运动部件的控制。

3. 印刷与包装机械：保障高精度同步运行和稳定性。

4. 纺织机械：控制复杂的多轴运动，提高效率与稳定性。

5. 通用工业自动化设备：适用于需要高动态响应的场合。

四、产品优势

• 高精度控制：信号处理能力强，保证电机运行平稳。

• 可靠性高：采用工业级设计，适应恶劣工况环境。

• 扩展性好：可与多种工业控制系统集成，兼容性强。

• 安全保护：内置完善的电气保护机制，延长设备寿命。

• 维护便捷：模块化设计，便于安装与更换。

英文资料：

1、 Product Overview

GIDINGS&LEWIS M.1302.6214 driver board is a core electronic control component used in industrial automation systems, mainly applied in servo systems, motion control, and the driving process of CNC machine tools. This drive board achieves high-speed response and stable operation of the motor through precise signal processing and current control, which is an important guarantee for the stable and efficient operation of complex mechanical equipment.

2、 Technical parameters (typical characteristics)

Model: M.1302.6214

Functional positioning: servo drive control board

Input voltage: matching industrial power specifications, with stable power filtering circuit

Output feature: Supports precise driving of servo motors/stepper motors

Control interface: compatible interface with upper computer, PLC or CNC system

Signal processing: high-speed response circuit, reducing delay and improving dynamic performance

Protection functions: overcurrent protection, overheating protection, short circuit protection

3、 Application scenarios

Numerical Control Machine Tool (CNC): Implementing servo drive and motor control in precision machining.

Automated production line: used for controlling key moving parts such as robots and conveyor equipment.

Printing and packaging machinery: ensuring high-precision synchronous operation and stability.

Textile machinery: Control complex multi axis movements to improve efficiency and stability.

General industrial automation equipment: suitable for situations that require high dynamic response.

4、 Product advantages

High precision control: Strong signal processing capability ensures smooth motor operation.

High reliability: Adopting industrial grade design to adapt to harsh working conditions and environments.

Good scalability: It can be integrated with various industrial control systems and has strong compatibility.

Security protection: Built in comprehensive electrical protection mechanism to extend equipment lifespan.

Convenient maintenance: Modular design, easy to install and replace.

2.产      品      展      示
