TOYOTA J9201-21002喷气编织机主板 PDF资料

1.产 品 资 料 介 绍：

产品概述

TOYOTA J9201-21002 主板是喷气编织机的核心控制电路单元，主要负责输入输出信号处理、织造工艺逻辑运算、执行机构协调以及与外围控制模块的通讯。它在喷气织机的运行中起到“大脑”的作用，保证高速、高精度和稳定的织造过程。

产品特点

1. 高可靠性设计

• 采用工业级电子元器件，抗干扰能力强，能够在高速运转和复杂环境下保持稳定。

• 具备过流、过压保护机制，降低因电气故障导致停机的风险。

2. 精确的信号处理能力

• 支持喷嘴、电磁阀、选色器等多通道输入/输出控制。

• 高速采样电路确保纬纱喷射的精准时序控制，提升织造质量。

3. 模块化结构

• 主板与传感器板、驱动板相互独立，便于维护和升级。

• 具有扩展接口，可支持不同规格喷气织机配置。

4. 优化的能效管理

• 合理分配电源和控制信号，降低能耗。

• 内置电源稳压电路，保证系统在电压波动时依然稳定工作。

5. 智能化功能支持

• 可与织机监控系统进行数据通讯，支持运行参数监测与故障诊断。

• 内置自检功能，能在开机时快速定位电路异常，减少停机时间。

应用价值

• 提升喷气织机的运行稳定性和织造精度。

• 支持高速生产环境下的连续作业。

• 降低维护成本，延长整机使用寿命。

英文资料：

Product Overview

The TOYOTA J9201-21002 motherboard is the core control circuit unit of the jet weaving machine, mainly responsible for input and output signal processing, weaving process logic operation, execution mechanism coordination, and communication with peripheral control modules. It plays the role of the "brain" in the operation of jet looms, ensuring high-speed, high-precision, and stable weaving processes.

Product Features

High reliability design

Using industrial grade electronic components, it has strong anti-interference ability and can maintain stability in high-speed operation and complex environments.

Equipped with overcurrent and overvoltage protection mechanisms to reduce the risk of shutdown caused by electrical faults.

Accurate signal processing capability

Support multi-channel input/output control for nozzles, solenoid valves, color selectors, and other devices.

The high-speed sampling circuit ensures precise timing control of weft yarn spraying, improving weaving quality.

Modular structure

The motherboard, sensor board, and driver board are independent of each other, making it easy to maintain and upgrade.

It has an expansion interface and can support different specifications of air-jet loom configurations.

Optimized energy efficiency management

Reasonably allocate power and control signals to reduce energy consumption.

Built in power regulator circuit ensures stable operation of the system even during voltage fluctuations.

Intelligent functional support

It can communicate data with the weaving machine monitoring system, support monitoring of operating parameters and fault diagnosis.

Built in self-test function, which can quickly locate circuit abnormalities during startup and reduce downtime.

applied value

Improve the operational stability and weaving accuracy of jet looms.

Support continuous operations in high-speed production environments.

Reduce maintenance costs and extend the service life of the entire machine.

2.产      品      展      示
