Magnetek CIMR-P5U4015 交流电驱动器 PDF资料

1.产 品 资 料 介 绍：

一、产品概述

Magnetek CIMR-P5U4015 是一款中高功率段的交流电驱动器，属于 Yaskawa GPD506 系列，适用于 25HP（约 18.5kW）三相交流感应电机的调速控制。该驱动器采用矢量控制和 V/f 控制方式，具备良好的电机启动性能和运行稳定性。

二、技术参数简要

• 型号：CIMR-P5U4015

• 电压等级：三相 380V–460V AC

• 额定功率：25 HP / 18.5 kW

• 输出电流：40 A

• 控制方式：V/f 控制、开环矢量控制

• 适配电机：标准三相感应电动机

三、应用领域

1. 水泵与风机系统

• 用于恒压供水、冷却水循环系统、暖通空调（HVAC）系统等，通过调节转速降低能耗，提升系统效率。

2. 输送与传送系统

• 应用于物流输送带、包装流水线、食品分拣线等场景，实现平稳启停和速度精准控制。

3. 加工与机床设备

• 适合铣床、钻床、木工机械、磨床等加工设备，提升加工过程中的转速控制精度与响应速度。

4. 工业自动化设备

• 包括卷扬机、提升装置、物料搬运设备、起重机械等，用于改善设备起动冲击，增强运行稳定性。

5. 风力或水力模拟系统

• 可在风洞测试、水力驱动试验平台等实验系统中用于模拟可变转速运行环境。

6. 印刷与纺织机械

• 应用于织布机、印刷输纸系统，满足精细调速和同步控制需求。

英文资料：

1、 Product Overview

Magnetek CIMR-P5U4015 is a medium to high power range AC drive, belonging to the Yaskawa GPD506 series, suitable for speed control of 25HP (approximately 18.5kW) three-phase AC induction motors. This driver adopts vector control and V/f control methods, and has good motor starting performance and operational stability.

2、 Brief Technical Parameters

Model: CIMR-P5U4015

Voltage level: three-phase 380V-460V AC

Rated power: 25 HP/18.5 kW

Output current: 40 A

Control methods: V/f control, open-loop vector control

Compatible motor: Standard three-phase induction motor

3、 Application Fields

Pump and fan system

Used for constant pressure water supply, cooling water circulation systems, HVAC systems, etc., by adjusting the speed to reduce energy consumption and improve system efficiency.

Conveying and conveying system

Applied to logistics conveyor belts, packaging assembly lines, food sorting lines, and other scenarios, achieving smooth start stop and precise speed control.

Processing and Machine Tool Equipment

Suitable for processing equipment such as milling machines, drilling machines, woodworking machinery, grinding machines, etc., to improve the speed control accuracy and response speed during the processing.

industrial automation equipment

Including winches, lifting devices, material handling equipment, lifting machinery, etc., used to improve equipment starting impact and enhance operational stability.

Wind or hydraulic simulation system

It can be used in experimental systems such as wind tunnel testing and hydraulic drive testing platforms to simulate variable speed operating environments.

Printing and Textile Machinery

Applied to weaving machines and printing paper feeding systems, meeting the requirements of fine speed regulation and synchronous control.

2.产      品      展      示
