The MVME172LX contains shared onboard DRAM whose base address

is software-selectable. Both the onboard processor and offboard VMEbus

devices see this local DRAM at base physical address $00000000, as

programmed by the MVME172Bug firmware. This may be changed via

software to any other base address. Refer to the MVME172 VME

Embedded Controller Programmer’s Reference Guide for more

information.

If the MVME172LX tries to access offboard resources in a nonexistent

location and is not system controller, and if the system does not have a

global bus timeout, the MVME172LX waits forever for the VMEbus cycle

to complete. This will cause the system to lock up. There is only one

situation in which the system might lack this global bus timeout: when the

MVME172LX is not the system controller and there is no global bus

timeout elsewhere in the system.

Multiple MVME172LXs may be installed in a single VME chassis. In

general, hardware multiprocessor features are supported.

Note If you are installing multiple MVME172LXs in an

MVME945 chassis, do not install an MVME172LX in slot

12. The height of the IP modules may cause clearance

difficulties in that slot position.

Other MPUs on the VMEbus can interrupt, disable, communicate with,

and determine the operational status of the processor(s). One register of the

GCSR (global control/status register) set includes four bits that function as

location monitors to allow one MVME172LX processor to broadcast a

signal to any other MVME172LX processors. All eight registers are

accessible from any local processor as well as from the VMEbus.The following circuits are protected by solid-state fuses that open during

overload conditions and reset themselves once the overload is removed:

❏ LAN AUI

❏ SCSI terminator

❏ Remote reset connector

❏ IndustryPack 5V

❏ ±12V

The FUSES LED illuminates to indicate that all fuses are functioning

correctly. If a fuse opens, power must be removed for several minutes to

allow the fuse to return to a closed or shorted condition.
