ABB 81AA03A-E GJR2394100R1210控制主板卡件
1.产 品 详 情 资 料：
双LED亮起。CI869模块在冗余配置中运行。Prim（ary）LED亮起。CI869模块在冗余配置中运行，它起到主模块的作用。注意：即使备份CI869模块在冗余配置中出现错误或故障，在冗余配置的主CI869模件中，Prim LED仍亮起。如果纠正措施是更换有故障的CI869模块，请将其更换为具有相同版本硬件和固件的另一个CI869模件。CI869支持热插拔。R（un）和F（ault）指示灯均不亮。ABB 81AA03A-E GJR2394100R1210单元正在配置中。如果这种情况持续存在，并且CEX总线上没有其他单元LED亮起：•检查是否将包括ABB 81AA03A-E GJR2394100R1210在内的有效硬件配置下载到控制器。•检查PM8xx处理器单元内的CEX总线保险丝。•从PM8xx处理器单元启动复位信号（INIT）。•更换ABB 81AA03A-E GJR2394100R1210装置。故障指示灯亮起ABB 81AA03A-E GJR2394100R1210装置正在重新启动过程中。等待重新启动操作完成。如果情况依然存在，请更换单元。RxTx1/RxTx2 LED熄灭接收和I/O数据传输不会在相应的以太网信道上发生。RxTx1/RxTx2 LED闪烁接收和I/O数据传输在相应的以太网信道上正常进行。PRIM关闭应用程序未启动ABB 81AA03A-E GJR2394100R1210。PRIM开启ABB 81AA03A-E GJR2394100R1210由应用程序启动。DUAL为OFF默认值，因为PROFINET IO不支持冗余。
Dual LED is ON The CI869 module is run in redundant configuration. Prim(ary) LED is ON The CI869 module is run in redundant configuration, and it functions as the primary module. Note: Even if the backup CI869 module runs with errors or fails in redundant configuration, the Prim LED is still ON in the primary CI869 module in redundant configuration. If the corrective action is to replace the faulty CI869 module, replace it with another CI869 module which has the same version of hardware and firmware. CI869 supports hot swap.Neither R(un) nor F(ault) LEDs are ON The ABB 81AA03A-E GJR2394100R1210 unit is in the process of configuration. If the condition persist, and no other unit LED on the CEX-Bus is ON: • Check that a valid hardware configuration including the ABB 81AA03A-E GJR2394100R1210 is downloaded to the controller. • Check the CEX-Bus fuse inside the PM8xx processor unit. • Initiate a reset signal (INIT) from the PM8xx processor unit. • Replace the ABB 81AA03A-E GJR2394100R1210 unit. F(ault) LED is ON The ABB 81AA03A-E GJR2394100R1210 unit is in the process of being restarted. Wait until the restart operation is complete. Replace unit if the condition persists. RxTx1/RxTx2 LED is OFF Reception and transmission of I/O data does not occur at the respective Ethernet channels. RxTx1/RxTx2 LED is flashing Reception and transmission of I/O data occurs normally at the respective Ethernet channels. PRIM is OFF The ABB 81AA03A-E GJR2394100R1210 is not started by the application. PRIM is ON The ABB 81AA03A-E GJR2394100R1210 is started by the application. DUAL is OFF Default, as no redundancy is supported with PROFINET IO.
