ABB 70EA05a-E HESG447419R1端子模块
1.产 品 详 情 资 料：
R（un）和F（ault）LED均不亮。ABB 70EA05a-E HESG447419R1正在重新启动或配置过程中。请留出时间以便最终确定。如果情况持续存在，并且CEX总线上的所有其他单元都有未点亮的LED：•检查是否将包括ABB 70EA05a-E HESG447419R1在内的有效硬件配置下载到控制器。•检查PM8xx处理器单元内的CEX总线保险丝。•从PM8xx处理器单元启动复位信号（INIT）。•更换CABB 70EA05a-E HESG447419R1 F（ault）LED亮起检查CABB 70EA 05a-E HeSG447419R11是否正在重新启动。请留出时间以便最终确定。检查CIABB 70EA05a-E HESG447419R1n CBM是否没有报告配置故障。如果状态仍然存在，则从PM8xx处理器单元启动复位信号（INIT）。如果复位后状态仍然保持，则更换CIABB 70EA05a-E HESG447419R1COMM ERROR LED为ON Field Bus Communication ERROR from theµGenie slave module（µ精灵从模块的现场总线通信错误）。PRIM LED熄灭CIABB 70EA05a-E HESG447419R1正在重新启动或配置过程中。请留出时间以便最终确定。检查CIABB 70EA05a-E HESG447419R1n CBM是否未报告配置故障。CIABB 70EA05a-E HESG447419R1上的DUAL LED熄灭。CIABB 70 EA05a-E HESG4474-19R1正在重新启动或配置过程中。请留出时间以便最终确定。检查该模块的冗余是否已在CBM中设置，并已下载配置。R（un）和F（ault）LED均不亮。CI865单元正在配置中。请留出时间以便最终确定。如果情况持续存在，并且CEX总线上的其他单元指示灯未点亮：•检查是否将包括CI865在内的有效硬件配置下载到控制器。•检查PM8xx处理器单元内的CEX总线保险丝•从PM8xx处理单元启动复位信号（INIT）•更换CI865单元F（故障）LED亮起CI865装置正在重新启动过程中。请留出时间以便最终确定。如果情况依然存在，请更换单元。
Neither R(un) nor F(ault) LED’s are ON The ABB 70EA05a-E HESG447419R1 is in the process of being restarted or configured. Allow time for this to finalize. If the condition persists, and all other units on the CEXbus have non-illuminated LEDs: • Check that a valid HW configuration including the ABB 70EA05a-E HESG447419R1 is downloaded to the controller. • Check the CEX-bus fuse inside the PM8xx processor unit. • Initiate a reset signal (INIT) from the PM8xx processor unit. • Replace the CABB 70EA05a-E HESG447419R1 F(ault) LED is ON Check that the CABB 70EA05a-E HESG447419R1is in the process of being restarted. Allow time for this to finalize. Check that there is no configuration fault reported from CIABB 70EA05a-E HESG447419R1n CBM.If the status remains, initiate a reset signal (INIT) from the PM8xx processor unit. If the status still remains after the reset replace the CIABB 70EA05a-E HESG447419R1COMM ERROR LED is ON Field Bus Communication Error from the µGenie slave module. PRIM LED is OFF The CIABB 70EA05a-E HESG447419R1s in the process of being restarted or configured. Allow time for this to finalize. Check that there is no configuration fault reported from CIABB 70EA05a-E HESG447419R1n CBM. DUAL LED is OFF on both CIABB 70EA05a-E HESG447419R1 The CIABB 70EA05a-E HESG447419R1s in the process of being restarted or configured. Allow time for this to finalize. Check that the redundancy for this module is set within CBM and the configuration is downloaded.Neither R(un) nor F(ault) LED’s are ON The CI865 unit is in the process of being configured. Allow time for this to finalize. If the condition persists, and no other unit LED on the CEX-Bus is lit: • Check that a valid HW configuration including the CI865 is downloaded to the controller. • Check the CEX-Bus fuse inside the PM8xx processor unit • Initiate a reset signal (INIT) from the PM8xx processor unit • Replace the CI865 unit F(ault) LED is ON The CI865 unit is in the process of being restarted. Allow time for this to finalize. Replace unit if the condition persists.
2.产 品 展 示
