RELIANCE 2GU42003工控控制卡件
1.产 品 介 绍
品牌：RELIANCE
型号说明：RELIANCE 2GU42003工控控制卡件
优势：供应进口原装正品，专业停产配件。
公司主营特点：主营产品各种模块/卡件，控制器，触摸屏，伺服驱动器。
2.产 品 详 情 资 料：
RELIANCE 2GU42003的支持功能由MC2芯片ASIC提供。有关详细编程信息，请参阅RELIANCE 2GU42003用户指南。可选SCSI接口MVME162FX嵌入式控制器可通过行业标准SCSI总线提供大容量存储子系统。这些子系统可能包括硬盘和软盘驱动器、流式磁带驱动器和其他大容量存储设备。SCSI接口使用NCR53C710 SCSI I/O控制器实现。MC2芯片ASIC提供了53C710的支持功能。有关详细编程信息，请参阅53C710用户指南。SCSI端接系统技术人员必须确保SCSI总线两端均正确端接。在控制器上，为P2适配器板或LCP2适配器板上的端子提供了插座。如果SCSI总线终止于适配器板，则必须在适配器板上安装终端电阻器+通过适配器板上的保险丝向SCSI总线TERM电源线和终端电阻器提供5V电源。RELIANCE 2GU42003
Support functions for the RELIANCE 2GU42003are provided by the MC2 chip ASIC. Refer to the RELIANCE 2GU42003 user's guide for detailed programming information. Optional SCSI Interface The MVME162FX Embedded Controller may provide for mass storage subsystems through the industry-standard SCSI bus. These subsystems may include hard and floppy disk drives, streaming tape drives, and other mass storage devices. The SCSI interface is implemented using the NCR 53C710 SCSI I/O controller.RELIANCE 2GU42003Support functions for the 53C710 are provided by the MC2 chip ASIC. Refer to the 53C710 user’s guide for detailed programming information. SCSI Termination The system technician must ensure that the SCSI bus is properly terminated at both ends. On the controller, sockets are provided for the terminators on the P2 adapter board or the LCP2 adapter board. If the SCSI bus ends at the adapter board, then termination resistors must be installed on the adapter board. +5V power to the SCSI bus TERM power line and termination resistors is provided through a fuse located on the adapter board.RELIANCE 2GU42003
3.产 品 展 示
4.公 司 优 势 主 营 产 品
5.相 关 产 品 展 示
本篇文章出自瑞昌明盛自动化设备有限公司官网，转载请附上此链接:http://www.jiangxidcs.com
