ABB RDCU-02C脉冲编码器接口
1.产 品 介 绍
品牌：ABB
型号：ABB RDCU-02C
产品说明：脉冲编码器接口
优势：供应进口原装正品，专业停产配件。
2.产 品 详 情 资 料：
ABB RDCU-02C32点模块的接线板快速连接组件32点模块不需要新面板，因为它们配备了双连接器面板作为标准功能。由于每个模块都有两个24针连接器，因此每个模块都需要两条电缆和两个接线板。此外，由于模块的两个连接器的方向不同（参见下图中的示例），因此两条电缆不同。其中一条被称为“右侧”电缆，另一条被称作“左侧”电缆。注：这些接线板不能与具有50针连接器的32点I/O模块一起工作。接线板接线板有三排端子，按三个级别排列，如图H-1所示。端子具有易于使用的固定螺钉、ABB RDCU-02C“上升笼”型连接系统。接线板及其可使用的模块的目录号如下所示。电缆选择和交叉参考六根电缆可用于连接模块面板连接器和接线板。这些电缆在模块端部具有直角连接器，以尽量减少模块前面所需的空间。这六条电缆取代了三条带有直接头的过时电缆。由于模块的两个连接器的方向不同（参见上图），因此需要右侧和左侧电缆。使用下表选择正确的电缆。该表还列出了由一对相同长度的右侧和左侧电缆组成的电缆套件。ABB RDCU-02C
Terminal Block Quick Connect Components for 32-Point Modules The 32-point modules do not require a new faceplate since they are equipped with a dual-connector faceplate as a standard feature. Since each module has two 24-pin connectors,ABB RDCU-02C they each require two cables and two terminal blocks. Also, since the modules’ two connectors are oriented differently (see example in figure below), the two cables are different. One is called a “right side” cable and the other, a “left side” cable. Note: These terminal blocks will not work with the 32-point I/O modules that have 50-pin connectors.Terminal Block Terminal blocks have three rows of terminals, arranged in three levels, as shown in Figure H-1. The terminals feature an easy to use captive-screw, “rising cage” type connection system.ABB RDCU-02C Catalog numbers for the terminal block and the modules it can be used with are listed below.Cable Selection and Cross-Reference Six cables are available for connecting between the modules’ faceplate connectors and the terminal blocks. These cables have right-angle connectors on the module end to minimize the space required in front of the modules. These six cables replace three obsolete cables that had straight connectors. Since the modules’ two connectors are oriented differently (see previous figure), a right-side and left-side cable is required. Use the following table to select the correct cables. The table also lists cable kits that consist of a pair of same length, right side and left side cables.ABB RDCU-02C
3.产 品 展 示
