ABB DI811 3BSE008552R1模块控制器
品牌：ABB
型号：ABB DI811 3BSE008552R1
产品说明：模块控制器
ABB DI811 3BSE008552R1模块控制器中文资料：
ABB DI811 3BSE008552R1模块控制器计算IC693PWR328的输入功率要求下图是典型的48 VDC电源效率曲线。确定48 VDC电源效率的基本程序如下所示。IC693PWR328电源的输入功率/电流计算Ŷ根据第2章中列出的单个模块的典型规格确定总输出负载。Ŷ使用图表确定平均输入功率。Ŷ将输入功率除以工作电源电压，以确定输入电流要求。Ŷ使用最低输入电压确定最大输入电流。考虑启动浪涌电流要求。Ŷ允许变化的裕度（0%至20%）。ABB DI811 3BSE008552R1IC693PWR31高容量电源，24 VDC输入90-30系列直流输入高容量电源（IC693PWR 33）是一个30瓦宽范围电源，设计用于24 VDC标称输入。对于需要比标准电源更大的+5V电流容量的应用，该电源允许+5V输出消耗所有30瓦。它将接受2 VDC至30 VDC的输入电压范围。尽管它能够在输入电压低至2 VDC的情况下将所有输出保持在规格范围内，但它不会以低于8 VDC的初始输入电压启动。该电源提供以下输出：Ŷ+5 VDC输出。Ŷ+24 VDC继电器电源输出，为90-30系列输出继电器模块上的电路供电。Ŷ某些模块内部使用的隔离+24 VDC，也可用于为24 VDC输入模块提供外部电源。该电源的每个输出的负载容量如下表所示。ABB DI811 3BSE008552R1
英文资料
Calculating Input Power Requirements for IC693PWR328 The following graph is a typical 48 VDC power supply efficiency curve. A basic procedure for determining efficiency of the 48 VDC power supply follows the figure.Input Power/Current Calculation for IC693PWR328 Power Supply Ŷ Determine total output load from typical specifications listed for individual modules in Chapter 2. Ŷ Use the graph to determine average input power. Ŷ Divide the input power by the operating source voltage to determine the input current requirements. Ŷ Use the lowest input voltage to determine the maximum input current. Ŷ Allow for start-up surge current requirements. Ŷ Allow margins (0% to 20%) for variations.IC693PWR331 High Capacity Power Supply, 24 VDC Input The Series 90-30 DC input High Capacity power supply (IC693PWR33) is a 30 watt wide range supply designed for 24 VDC nominal inputs. For applications requiring greater +5V current capacity than is available with the standard supply, this supply allows all 30 watts to be consumed from the +5 V output. It will accept an input voltage range from 2 VDC to 30 VDC. Although it is capable of maintaining all outputs within specifications with input voltages as low as 2 VDC, it will not start with initial input voltages of less than 8 VDC. This power supply provides the following outputs: Ŷ +5 VDC output. Ŷ +24 VDC Relay power output which provides power to circuits on Series 90-30 Output Relay modules. Ŷ Isolated +24 VDC, which is used internally by some modules, can also be used to provide external power for 24 VDC Input modules. The load capacity for each output of this power supply is shown in the following table.
