ABB FIO100 PHBFIO10010000模拟输出模块
ABB FIO100 PHBFIO10010000模拟输出模块中文资料：
ABB FIO100 PHBFIO10010000模拟输出模块它们主要用作现有装置的替代品。对于新安装，我们建议采用双24针连接器样式，因为它们具有旧模块（LED指示灯、TBQC）上没有的其他功能，并且更容易为它们制造定制长度的电缆。此处提供了安装信息，以方便仍在使用这些模块的用户ABB FIO100 PHBFIO10010000模拟输出模块。使用Weidmuller#912263接线板注意：TBQC不适用于这些模块，但您可以从您的电子产品分销商处购买用于此应用的Weidmuller#912263。安装Weidmuller#912263接线板。它有一个50针连接器和一个端子板，安装在标准的35毫米DIN导轨上。Ŷ将IC693CBL306/307电缆连接在模块面板连接器和魏德米勒接线板上的连接器之间。电缆数据见第10章。Ŷ将I/O设备连接到接线板。有关引脚输出信息，请参阅GFK-0898系列90-30 PLC I/O模块规格手册ABB FIO100 PHBFIO10010000模拟输出模块
英文资料
They are mainly used as replacements for existing installations. For new installations, we recommend the dual 24-pin connector style because they have additional features not found on the older modules (LED indicators, TBQC), and it is much easier to fabricate custom-length cables for them. Installation information is provided here for the convenience of those still using these modules. Using Weidmuller #912263 Terminal Block Note: The TBQC is not available for these modules, but you may purchase a Weidmuller #912263 from your electronics distributor for this application. Ŷ Mount the Weidmuller#912263 terminal block. It has a 50-pin connector and a terminal strip, and mounts on a standard 35 mm DIN-rail. Ŷ Connect an IC693CBL306/307 cable between the module’s faceplate connector and the connector on the Weidmuller terminal block. See Chapter 10 for cable data. Ŷ Wire I/O devices to the terminal block. See the Series 90-30 PLC I/O Module Specifications Manual, GFK-0898, for pin-out informationABB FIO100 PHBFIO10010000模拟输出模块
