ABB IIADP02 PLC/DCS备件模块
ABB DSAO120 57120001-EY数字量输入卡件中文资料：
ABB IIADP02 PLC/DCS备件模块一般布线指南警告除以下布线建议外，我们强烈建议您遵守适用于您所在区域或设备类型的所有布线和安全规范。例如，在美国，大多数地区都采用了国家电气规范标准，并规定所有布线都符合其要求。在其他国家，将适用不同的规范ABB IIADP02。为了确保人员和财产的最大安全，您必须遵守这些规范。否则可能导致人身伤害或死亡、财产损失或破坏，或两者兼而有之。颜色编码电线这些颜色编码通常用于美国制造的工业设备。此处引用它们作为参考。如果它们与适用于您所在地区或设备类型的规范相冲突，则应遵循适用的规范。除了满足代码要求，电线颜色编码使测试和故障排除更安全、更快、更容易。Ŷ绿色或带条纹的绿色-接地\374；黑色-初级交流\374红色-次级交流ŵ蓝色-直流\374*白色-公共或中性\374@黄色-次级电源不受主断路器控制。提醒维护人员，即使设备与主电源断开，也可能存在电源（来自外部电源）。ABB IIADP02
英文资料
General Wiring Guidelines Warning In addition to the following wiring suggestions, we strongly urge that you follow all wiring and safety codes that apply to your area or your type of equipment. For example, in the United States, most areas have adopted the National Electrical Code standard and specify that all wiring conform to its requirements. In other countries, different codes will apply. For maximum safety to personnel and property you must follow these codes. Failure to do so can lead to personal injury or death, property damage or destruction, or both. Color Coding Wires These color codes are commonly used in industrial equipment manufactured in the United States. They are cited here as a reference. Where they are in conflict with codes that apply to your area or your type of equipment, you should follow your applicable codes instead. Besides satisfying code requirements, wire color coding makes testing and troubleshooting safer, faster, and easier. Ŷ Green or green with stripe- Ground Ŷ Black - Primary AC Ŷ Red - Secondary AC Ŷ Blue - DC Ŷ White - Common or neutral Ŷ Yellow - Secondary power source not controlled by the main disconnect. Alerts maintenance personnel that there may be power present (from an external source) even if the equipment is disconnected from its main power source.ABB IIADP02
