ABB IIMKM01A控制模块
ABB IIMKM01A控制模块中文资料：
ABB IIMKM01A控制模块请勿在通电的情况下插入或移除模块。这可能导致PLC停止或故障。可能导致人员受伤和模块或基板损坏。此外，试图将模块推入不正确的插槽类型将导致模块和/或基板损坏。模块将以最小的力轻松安装在正确的插槽类型中。将模块插入基板插槽时，请使用以下说明作为指导。Ŷ检查模块目录号是否与插槽配置匹配。在配置过程中，每个插槽都或将被分配特定的模块类型。电源模块只能安装在左端未编号的插槽中，CPU模块和一些特殊选项模块只能安装于CPU底板的插槽1中。I/O模块和大多数选件模块安装在编号为2或更高的插槽中。ABB IIMKM01AŶ紧紧抓住模块，端子板朝向您，后枢轴钩背对您。Ŷ将模块与所需的基板插槽和连接器对齐。向上倾斜模块，使模块的顶部后部枢轴钩与基板的顶部模块固定器接合。Ŷ向下摆动模块，直到模块连接器与底板底板连接器接合，模块底部的释放杆卡入底板底部模块固定器中。Ŷ目视检查模块，确保其正确就位。ABB IIMKM01A
英文资料
Do not insert or remove modules with power applied. This could cause the PLC to stop or malfunction. Injury to personnel and damage to the module or baseplate may result. Also, attempts to force a module into an improper slot type will result in damage to the module and/or the baseplate. Modules will mount in the correct slot type easily, with a minimum of force. Use the following instructions as a guide when inserting a module into a baseplate slot. Ŷ Check that module catalog number matches slot configuration. Each slot is, or will be, assigned a particular module type during configuration. A Power Supply module must be installed in the left end unnumbered slot only, and a CPU module and some special Option modules can only be installed in Slot 1 of a CPU baseplate. I/O Modules and most Option modules install in slots numbered 2 and higher. Ŷ Grasp the module firmly with terminal board toward you and with rear pivot hook facing away from you. Ŷ Align the module with the desired baseplate slot and connector. Tilt the module upwards so that top rear pivot hook of the module engages the baseplate’s top module retainer. Ŷ Swing the module downward until the module’s connector engages the baseplate’s backplane connector, and the release lever on the bottom of the module snaps into place in the baseplate’s bottom module retainer. Ŷ Visually inspect the module to be sure that it properly seated.ABB IIMKM01A
