ABB IMAMM03模拟主模块
ABB IMAMM03模拟主模块中文资料：
ABB IMAMM03模拟主模块90系列-30可编程逻辑控制器（PLC）是GE Fanuc Series 90 PLC系列的成员。90-30系列PLC的基本部件90-30系列可编程逻辑控制器是非常通用的，因为（1）它是可编程的，（2）它是由多种模块化、插接式组件组装而成。因此，通过选择正确的组件和开发适当的程序，PLC可以用于几乎无限的应用。虽然在系统中使用的单个硬件组件有很多种选择，但只有几个基本类别。本手册的单独章节详细介绍了这些组件类别中的每一个。本章将介绍它们，以便您了解它们是如何组合在一起的：基板电源CPU I/O模块选项模块电缆基板基板是PLC系统的基础，因为大多数其他组件都安装在基板上。作为基本的最低要求，每个系统至少有一个基板，ABB IMAMM03模拟主模块通常包含CPU（在这种情况下，它被称为“CPU基板”）。许多系统需要比安装在一个基板上的模块更多的模块，因此也有扩展和远程基板连接在一起。CPU、扩展和远程三种类型的底板有两种尺寸，5插槽和10插槽，根据其可容纳的模块数量命名。电源模块每个基板都必须有自己的电源。电源始终安装在基板最左侧的插槽中。有几种电源型号可满足各种要求。ABB IMAMM03模拟主模块
英文资料
The Series 90-30 Programmable Logic Controller (PLC) is a member of the GE Fanuc Series 90 PLC family. The Basic Parts of a Series 90-30 PLC The Series 90-30 PLC is very versatile because (1) it is programmable, and (2) it is assembled from a wide variety of modular, plug-together components. Therefore, by choosing the correct components and developing an appropriate program, the PLC can be used for an almost unlimited variety of applications. Although there are many choices of individual hardware components to use in a system, there are just a few basic categories. Each of these component categories is covered in detail in a separate chapter in this manual. They are introduced in this chapter so you can see how they fit together: Baseplates Power Supplies CPUs I/O Modules Option Modules Cables Baseplates The baseplates are the foundation of the PLC system because most other components mount on them. As a basic minimum, every system has at least one baseplate, which usually contains the CPU (in which case, it is referred to as “the CPU Baseplate”). Many systems require more modules than can be mounted on one baseplate, so there are also Expansion and Remote baseplates that connect together. The three categories of baseplates, CPU, Expansion, and Remote, are available in two sizes, 5-slot and 10-slot, named according to the number of modules they can hold. Power Supply Modules Every baseplate must have its own power supply. The power supply always mounts in a baseplate’s left-most slot. There are several power supply models available to meet a variety of requirements.ABB IMAMM03模拟主模块
