ABB APSAF03 E32086 GJR5250000R0353机器人模块
ABB APSAF03 E32086 GJR5250000R0353子信号“暴露子信号”对话框允许您添加连接到子对象中信号的新I/O信号。以下控件可用：信号名称指定要创建的信号的名称。默认情况下，它与所选子信号的名称相同。子对象指定要为其公开信号的对象。子信号指定子信号。I/O连接组件中包含的I/O连接显示在网格中。以下控件可用：添加I/O连接打开“添加I/O连接”对话框。编辑打开“编辑I/O连接”对话框。ABB APSAF03 E32086 GJR5250000R0353管理I/O连接打开“管理I/O连接”对话框。删除删除选定的连接。上移或下移通过在列表中上下移动所选连接来排序。添加或编辑I/O连接“添加I/O连接”对话框允许您创建I/O连接或编辑现有连接。以下控件可用：源对象指定源信号的所有者。源信号指定连接的源。源必须是子组件的输出或当前组件的输入。ABB APSAF03 E32086 GJR5250000R0353
ABB APSAF03 E32086 GJR5250000R0353机器人模块
ose Child signal The Expose Child Signal dialog box allows you to add a new I/O signal that is connected to a signal in a child object. The following controls are available:Signal Name Specifies the name of the signal to be created. By default, it is the same as the name of the selected child signal. Child Object Specifies the object for which to expose a signal. Child Signal Specifies the child signal.I/O Connections The I/O Connections contained in the component are displayed in a grid. The following controls are available:Add I/O Connection Opens the Add I/O Connection dialog box. Edit Opens the Edit I/O Connection dialog box. Manage I/O Connections Opens the Manage I/O Connections dialog box. Delete Deletes the selected connection. Move Up or Move Down Sorts by moving the selected connections up and down the list.Add or Edit I/O Connection The Add I/O Connection dialog box allows you to create an I/O connection or edit an existing connection. The following controls are available:Source Object Specifies the owner of the source signal. Source Signal Specifies the source of the connection. The source must either be an output from a child component, or an input to the current component.ABB APSAF03 E32086 GJR5250000R0353
