ABB S200-IE8 490176097模拟输入模块
ABB S200-IE8 490176097三点如果要使用三点创建框架，请选择此选项。X轴上的第一个点单击其中一个框，然后单击图形窗口中的点位置，将值传递到X轴上第一个点框。X轴上的第二个点在其中一个框中单击，然后单击图形窗口中的点位置，将值传输到X轴上第二点框。Y轴上的点在其中之一框中单击并单击图形窗口的点位置将值传输至Y轴上点框。设置为UCS选中此复选框可将创建的框架设置为用户坐标系。创建工作对象1。单击“训练对象”以打开对话框。2.在“杂项数据”组中，输入新工作对象的值。3.在“用户帧”组中，执行以下操作之一：•通过单击“值”框，输入工作对象的“位置x、y、z”和“旋转rx、ry、rz”值，设置用户帧的位置。•使用“逐点框”对话框选择用户框。4.在“对象帧”组中，您可以通过执行以下任一操作来相对于用户帧重新定位对象帧：•通过单击“值”框，选择“位置x、y、z”ABB S200-IE8 490176097的值来设置对象帧的位置
ABB S200-IE8 490176097Three Point Select this option if you want to create the frame by using three
points.
First Point on X axis Click in one of these boxes, and then click the point position in
the graphics window to transfer the values to the First Point on
X axis boxes.
Second Point on X axis Click in one of these boxes, and then click the point position in
the graphics window to transfer the values to the Second Point
on X axis boxes.Point on Y axis Click in one of these boxes, and then click the point position in
the graphics window to transfer the values to the Point on Y
axis boxes.
Set as UCS Select this check box to set the created frame as the userABB S200-IE8 490176097coordinate system.Creating a workobject
1. Click Workobject to bring up a dialog box.
2. In the Misc Data group, enter the values for the new workobject.
3. In the User Frame group, do one of the following:
• Set the position of the user frame by entering values for the Position x, y, z and the
Rotation rx, ry, rz for the workobject by clicking in the Values box.
• Select the user frame by using the Frame by points dialog box.
4. In the Object Frame group you can reposition the object frame relative to the user frame
by doing any of the following:
• Set the position of the object frame by selecting values for Position x, y, z by clicking
in the Values box
