触摸屏中空气的外观触摸屏的层结构包含空气，在极少数情况下会出现气泡。这纯粹是装饰性的，不会影响操作员面板的任何功能。这种现象可能发生在某些环境条件下，如温度、湿度和大气压力。3BSE069463-600 Rev D 15触摸屏中空气的外观第2节安全注意事项16 3BSE089463-600 Rev.D第3节安装空间要求•最大安装板厚度：8 mm•安装操作面板时的空间要求（以毫米为单位）：410 mm 286 mm 100 mm 50 mm 50 mm 100 mm 53 mm图纸上的尺寸不成比例。3BSE069463-600 Rev D 17安装流程第3节安装安装流程需要以下步骤：•Torx TX7螺丝刀1。拆开包装并检查交货情况。如果发现损坏，请通知供应商。2.安装期间，将操作面板放置在稳定的表面上。操作面板掉落或掉落可能会造成损坏。3.要为操作员面板切割正确的开口，请使用外形图中的切割尺寸。有关详细信息，请参阅操作面板图纸和技术数据部分。4.通过拧紧M4 Torx螺钉将操作员面板固定到位Appearance of Air in Touch Screen The layer structure of the touch screen contains air and in rare cases appearance of bubbles can arise. This is purely cosmetic and does not affect any functionality of the operator panel. The appearance can occur under certain environmental conditions such as temperature, humidity, and atmospheric pressure. 3BSE069463-600 Rev D 15 Appearance of Air in Touch Screen Section 2 Safety Precautions 16 3BSE069463-600 Rev D Section 3 Installation Space Requirements • Maximum installation plate thickness: 8 mm • Space requirements in millimeters when installing the operator panel: 410 mm 286 mm 100 mm 50 mm 50 mm 100 mm 100 mm 53 mm The dimensions on the drawing are not proportional. 3BSE069463-600 Rev D 17 Installation Process Section 3 Installation Installation Process The following is needed: • A Torx TX7 screwdriver 1. Unpack and check the delivery. If damage is found, notify the supplier. 2. Place the operator panel on a stable surface during installation. Dropping the operator panel or letting it fall may cause damage. 3. To cut a correct opening for the operator panel, use the cut out dimensions in the outline drawing. For more information, see sections Operator Panel Drawings and Technical Data. 4. Secure the operator panel in position by screwing the M4 Torx screw, allowing t
