ABB DSQC301 3HAA3573-ABA通讯模块
注意！服务端口只能用于直接连接到本程序中所述的PC。它不能连接到LAN（局域网），因为它有一个DHCP服务器，可以自动向连接到LAN的所有单元分配IP地址。有关详细信息，请与网络管理员联系。注意！使用robapi连接的网络客户端的最大数量为：•LAN:3•服务：1•FlexPendant:1在连接到一个控制器的同一台PC上运行的使用robapi的应用程序的最大总数没有内置最大值；然而，UAS将登录用户的数量限制为50。同时连接的FTP客户端的最大总数为4个。端口DSQC639下图显示了计算机单元上的两个主要端口：服务端口和LAN端口。请确保LAN（工厂网络）未连接到任何服务端口！端口DSQC639下图显示了计算机单元上的两个主要端口：服务端口和LAN端口。请确保LAN（出厂网络）未连接到任何服务端口！
NOTE!
The service port shall only be used for direct connection to a PC as described in this
procedure. It must not be connected to a LAN (Local Area Network), since it has a DHCP
server that automatically distributes IP addresses to all units connected to the LAN.
Contact your network administrator for more information.
NOTE!
The maximum number of connected network clients using robapi is:
• LAN: 3
• Service: 1
• FlexPendant: 1
The total max. number of applications using robapi running on the same PC connected to one
controller has no built-in maximum; however, UAS limits the number of logged-on users to
50.
The total max. number of concurrently connected FTP clients is 4.Ports DSQC639
The illustration below shows the two main ports on the computer unit: the Service Port and
the LAN port. Make sure the LAN (factory network) is not connected to any of the service
ports!Ports DSQC639
The illustration below shows the two main ports on the computer unit: the Service Port and
the LAN port. Make sure the LAN (factory network) is not connected to any of the service
ports!
