CAUTION: Some of the components assembled on VMIC’s products may be sensitive
to electrostatic discharge and damage may occur on boards that are subjected to a
high energy electrostatic field. When the board is placed on a bench for configuring,
etc., it is suggested that conductive material be inserted under the board to provide a
conductive shunt. Unused boards should be stored in the same protective boxes in
which they were shipped.Hardware Setup
The VMIVME-7750 is factory populated with user-specified options as part of the
VMIVME-7750 ordering information. The CPU speed, RAM size and flash memory
size are not user-upgradable. To change CPU speeds or RAM/Flash size, contact
customer service to receive a Return Material Authorization (RMA).The VMIVME-7750 is tested for system operation and shipped with factory-installed
header jumpers. The physical location of the jumpers and connectors for the single
board CPU are illustrated in Figure 1-1 on page 27. The definitions of the CPU board
jumpers and connectors are included in Table 1-1 through Table 1-7.
CAUTION: All jumpers marked User Configurable in the following tables may be
changed or modified by the user. All jumpers marked factory configured should not
be modified by the user.
