EMERSON 1C31113G02模拟输入模块
从转换模块前面板上拆下PIM填充物。4.将无源互调模块的面板（前挡板）从后面滑入前面板开口，并将无源互互调模块放置在过渡模块的顶部，与相应的两个无源互调连接器对齐。然后，PIM模块下侧的两个连接器应与转换模块上的相应连接器（J10和J14）平滑连接。5.将PIM附带的四个短十字螺丝穿过转换模块底部的孔插入PIM前挡板和后支架。拧紧螺钉。有关正确的螺钉/板对齐，请参阅下图。下面的示例可能无法准确地表示您的MVME7100。概述MOTLoad固件包用作板加电和初始化包，以及可以启动用户应用程序的车辆。
Remove the PIM filler from the front panel of the transition module. 4. Slide the face plate (front bezel) of the PIM module into the front panel opening from behind and place the PIM module on top of the transition module, aligned with the appropriate two PIM connectors. The two connectors on the underside of the PIM module should then connect smoothly with the corresponding connectors on the transition module (J10 and J14). 5. Insert the four short Phillips screws, provided with the PIM, through the holes on the bottom side of the transition module into the PIM front bezel and rear standoffs. Tighten the screws. Refer to the following figure for proper screw/board alignment. The example below may not accurately represent your MVME7100.Overview The MOTLoad firmware package serves as a board power-up and initialization package, as well as a vehicle from which user applications can be booted.
