GE DS200SHVMG1A高压M帧接口板
该窗口包括当前光标线位置的波形值和显示所需波形的复选框。Z选择从设备读取最后一次触发，以从PQM加载先前采集的波形。打开加载并查看先前保存的波形，保存保存捕获的波形，打印当前显示的波形，设置允许用户更改捕获参数。跟踪存储器跟踪存储器功能允许设置PQM以在各种条件下触发。跟踪存储器可以同时记录所有电压和电流输入的最多36个数据周期（每个周期16个样本）。已在寄存器0x0B83处的PQM内存映射中实现了总跟踪触发计数器。该寄存器将保持自上次向PQM通电以来所有有效跟踪存储器触发器的运行总数。Total Trace Triggers计数器将在65536滚动到0。
The window includes waveform values for the current cursor line position and check boxes to display the desired waveforms. Z Select Read Last Trigger From Device to load previous acquired waveforms from the PQM. Open loads and views previously save waveforms, Save saves the captured waveforms, Print prints the currently displayed waveforms, and Setup allows the user to change the capture parameters.Trace Memory The trace memory feature allows the PQM to be setup to trigger on various conditions. The trace memory can record maximum of 36 cycles of data (16 samples per cycle) for all voltage and current inputs simultaneously. A Total Trace Triggers Counter has been implemented in the PQM Memory Map at Register 0x0B83. This register will keep a running total of all valid Trace Memory Triggers from the last time power was applied to the PQM. The Total Trace Triggers counter will rollover to 0 at 65536.
