GE DS200UPSAG1A电源板
脉冲输入1：此消息显示基于自上次复位以来计数的脉冲总数的累积值。一个开关输入脉冲等于S2系统设置\脉冲输入\脉冲输入1值设置点中指定的值。值后显示的单位如S2 SYSTEM SETUP\PULSE INPUT\PULSE INPUT units（S2系统设置\脉冲输入\脉冲输入单位）设定值中所定义。一旦达到值4294967295（FFFFFFFF h），显示的值将滚动到0。要使用此功能，必须安装“C”（控制）选项，并且必须将一个PQM开关输入分配给PULSE INPUT 1功能。然后，开关输入将根据开关的配置计算闭合或打开的数量。有关开关输入编程的详细信息，请参见设定点页面S2 SYSTEM SETUP\SWITCH INPUT A/B/C/D。最低时间要求如下图5.11所示。PULSE INPUT 2：请参阅上述PULSE Input1描述，并将PULSE INPUT 1的所有引用替换为PULSE INPUT 2。
PULSE INPUT 1: This message displays the accumulated value based on total number of pulses counted since the last reset. One switch input pulse is equal to the value assigned in the S2 SYSTEM SETUP \ PULSE INPUT \ PULSE INPUT 1 VALUE setpoint. The units shown after the value are as defined in the S2 SYSTEM SETUP \ PULSE INPUT \ PULSE INPUT UNITS setpoint. The displayed value will roll over to 0 once the value 4294967295 (FFFFFFFFh) has been reached. To use this feature, the “C” (control) option must be installed and one of the PQM switch inputs must be assigned to PULSE INPUT 1 function. The switch input will then count the number of closures or openings depending upon how the switch is configured. See setpoints page S2 SYSTEM SETUP \ SWITCH INPUT A/B/C/D for details on programming the switch inputs. The minimum timing requirements are shown below in Figure 5.11. PULSE INPUT 2: See the PULSE INPUT 1 description above and replace all references to PULSE INPUT 1 with PULSE INPUT 2.
