GE DS3800HISAIAIA输入输出模块
例如，更改以下设置点：S5测试\模拟输出模拟\模拟输出1:50.0%S5测试\仿真输出模拟\仿真：开启模拟输出1上的输出电流水平将为12 mA（4至20mA）或0.5 mA（0至1mA）。•模拟：输入ON从实际模拟输入切换到编程模拟值。模拟完成后，将此设定点设置为OFF。•SIMULATION ENABLED FOR（模拟启用时间）：选择将启用模拟的所需时间长度。编程时间过去后，模拟输入模拟将关闭。如果选择了无限制，则将使用模拟模拟输入，直到通过simulation（模拟）设置点或串行端口关闭模拟，或直到PQM中的控制电源断开。•模拟输入：输入要模拟的4至20 mA范围内的模拟输入电流。
For example, alter the setpoints below: S5 TESTING \ ANALOG OUTPUTS SIMULATION \ ANALOG OUTPUT 1: 50.0% S5 TESTING \ ANALOG OUTPUTS SIMULATION \ SIMULATION: ON The output current level on analog output 1 will be 12 mA (4 to 20mA) or 0.5 mA (0 to 1mA).• SIMULATION: Enter ON to switch from an actual analog input to the programmed simulated value. Set this setpoint OFF after simulation is complete. • SIMULATION ENABLED FOR: Select the desired length of time that simulation will be enabled. When the programmed time has elapsed, analog input simulation will turn off. If unlimited is selected, the simulated analog input will be used until simulation is turned off via the SIMULATION setpoint or via the serial port or until control power is removed from the PQM. • ANALOG INPUT: Enter an analog input current in the range of 4 to 20 mA to be simulated.
