GE Multilin UR8AH模块卡件
•捕获和显示电压和电流波形以进行分析•记录各种测量量的需求曲线•使用内置通信调试工具排除通信问题•打印所有图表、设定值、，EnerVista PQM设置软件详见第章：软件基本单元PQM I I I I II I I I基本单元，带显示器、所有电流/电压/功率测量、1个RS485通信端口、1个RS232通信端口传感器选件T20 I I I 4隔离模拟输出、0-20 mA和4-20 mA可分配给所有测量参数、4-20 mA模拟输入、，第二RS485通信端口T1 I I I I 4个隔离模拟输出，0-1 mA可分配给所有测量参数，4-20 mA模拟输入，第二RS485通讯端口控制选项C I 3个附加可编程输出继电器（共4个），4个可编程开关输入功率分析选项a谐波分析，触发跟踪存储器，波形捕获，事件记录器，数据记录器• capture and display voltage and current wave shapes for analysis • record demand profiles for various measured quantities • troubleshoot communication problems with a built in communications debugging tool • print all graphs, charts, setpoints, and actual data The EnerVista PQM Setup software is fully described in Chapter : Software Basic Unit PQM I I I I I I I I I Basic Unit with display, all current/voltage/power measurements, 1 RS485 communication port, 1 RS232 communication port Transducer Option T20 I I I I I I 4 isolated analog outputs, 0-20 mA and 4-20 mA assignable to all measured parameters, 4-20 mA analog input, 2nd RS485 communication port T1 I I I I I I 4 isolated analog outputs, 0-1 mA assignable to all measured parameters, 4-20 mA analog input, 2nd RS485 communication port Control Option C I I 3 additional programmable output relays (for a total of 4), 4 programmable switch inputs Power Analysis Option A Harmonic analysis, triggered trace memory, waveform capture, event recorder, data logger
