ASIC位于$FFF4202C位23-16。功能描述http://www.mcg.mot.com/literature1-19 1 I/O接口MVME162FX嵌入式控制器为许多系统应用提供板载I/O。I/O功能包括串行端口、Industry Pack接口、可选LAN以太网收发器接口和可选SCSI大容量存储接口。串行通信接口控制器使用Zilog Z85230串行通信控制器来实现两个串行通信接口。每个接口支持CTS、DCD、RTS和DTR控制信号；以及TxD和RxD发送/接收数据信号和TxC/RxC同步时钟信号。Z85230支持同步（SDLC/HDLC）和异步协议。控制器的硬件支持110b/s至38.4Kb/s的异步串行波特率。Z85230在中断确认周期内提供中断向量。矢量根据Z85230内的中断源进行修改。中断请求级别通过MC2芯片编程。一个MC2芯片最多可处理四个Z85230芯片。有关信息，请参阅附录F中所示的Z85230数据表和MVME162FX嵌入式控制器程序员参考指南中的MC2芯片编程模型。MVME162FX串行端口1 Z85230的A端口作为DCE（数据电路终端设备）与EIA-232-D接口连接，并路由至：❏ 控制器前面板上标记为SERIAL PORT 1/CONSOLE的DB-25连接器。串行端口1/CONSOLE是EIA-232-D DCE端口。注意：该端口可以连接到DB-25连接器上可能存在的TX和RX时钟。这些连接通过控制器上的跨接线头J11进行。注意，MVME712x转换模块上没有TxC和RxC时钟线。1-20计算机组文献中心网站板级硬件描述1❏ MVME712x转换模块上的以下输出连接器之一：MVME712M：前面板上标记为SERIAL PORT 2的DB-25连接器。串行端口2可以通过跳线头J16和J17配置为EIA-232-D DTE或DCE端口。MVME712A或MVME712-12：前面板上标记为串行端口2的DB-9连接器。串行端口2硬接线为EIA-232-D DTE端口。MVME712AM或MVME712-13：标有串行端口2的DB-9连接器或前面板上的RJ-11插孔。串行端口2硬接线为EIA-232-D DTE；RJ-11插孔使用内置调制解调器。在MVME712AM/-13上设置跳线头J16和J17可将输出配置为串行端口2处的EIA-232-D DTE或RJ-11插孔处的调制解调器。第2章中的图2-3（表1和表2）说明了当控制器与MVME712M一起使用时端口A可用的两种配置。图2-5（表1和表2）显示了当控制器与MVME712A/AM/-12/-13一起使用时，端口A可用的两种配置。MVME162FX串行端口2 Z85230的B端口配置通过安装在控制器连接器J10上的串行接口模块（SIMM）确定。有五种SIMMS可用：SIMM05-带EIA-232-D接口的DTE SIMM06-带EIA-332-D接口接口的DCE SIMM07-带EIA-530接口的DTD SIMM08-带EIA-530接口的DCD SIMM09-EIA-485接口，或带EIA-422接口的DCC或DTE端口B通过SIMM路由到：❏ MVME162FX控制器前面板上标记为SERIAL PORT 2的DB-25连接器。串行端口2将是EIA232-D DCE或DTE端口，或EIA-530 DCE或DCE端口，或者EIA-485端口，或者是EIA-422 DCE或DTE端口，具体取决于安装的模块。功能描述http://www.mcg.mot.com/literature1-21 1注意端口B在工厂配置为异步通信。对于同步通信，该端口可以连接到DB-25连接器上可能存在的TX和RX时钟信号。这些连接通过控制器上的跨接线头J12进行。TxC和RxC时钟线可通过该板上的接头J15在MVME712M串行端口4上使用，但在其他MVME712x转换模块上不可用。❏ MVME712x转换模块上的以下输出连接器之一：MVME712M：前面板上标记为SERIAL PORT 4的DB-25连接器。串行端口4可通过MVME712M上的跳线头J18和J19配置为EIA-232-D DTE或DCE端口。MVME712A、AM、-12或-13：前面板上标记为串行端口4的DB-9连接器。串行端口4硬接线为EIA-232-D DTE端口。第2章中的图2-3（表3至表6）显示了MVME162FX嵌入式控制器与MVME712M一起使用时端口B可用的四种配置。注意，图2-3表5和6中所示的端口配置不建议用于同步应用
ASIC at location $FFF4202C bits 23-16. Functional Description http://www.mcg.mot.com/literature 1-19 1 I/O Interfaces The MVME162FX Embedded Controller provides onboard I/O for many system applications. The I/O functions include serial ports, Industry Pack interfaces, optional LAN Ethernet transceiver interface, and an optional SCSI mass storage interface. Serial Communications Interface The controller uses a Zilog Z85230 serial communications controller to implement the two serial communications interfaces. Each interface supports CTS, DCD, RTS, and DTR control signals; as well as the TxD and RxD transmit/receive data signals, and TxC/RxC synchronous clock signals. The Z85230 supports synchronous (SDLC/HDLC) and asynchronous protocols. The controller’s hardware supports asynchronous serial baud rates of 110b/s to 38.4Kb/s. The Z85230 supplies an interrupt vector during interrupt acknowledge cycles. The vector is modified based upon the interrupt source within the Z85230. Interrupt request levels are programmed via the MC2 chip. One MC2 chip can handle up to four Z85230 chips. Refer to the Z85230 data sheet shown in Appendix F, and to the MC2 chip Programming Model in the MVME162FX Embedded Controller Programmer’s Reference Guide, for information. MVME162FX Serial Port 1 The A port of the Z85230 is interfaced as DCE (data circuit-terminating equipment) with the EIA-232-D interface and is routed to: ❏ The DB-25 connector marked SERIAL PORT 1/CONSOLE on the front panel of the controller. SERIAL PORT 1/CONSOLE is an EIA-232-D DCE port. NOTE: This port can be connected to the TX and RX clocks which may be present on the DB-25 connector. These connections are made via jumper header J11 on the controller. Note that the TxC and RxC clock lines are not available on the MVME712x transition modules. 1-20 Computer Group Literature Center Web Site Board Level Hardware Description 1 ❏ One of the following output connectors on the MVME712x transition module: MVME712M: The DB-25 connector marked SERIAL PORT 2 on the front panel. SERIAL PORT 2 can be configured as an EIA-232- D DTE or DCE port, via jumper headers J16 and J17. MVME712A or MVME712-12: The DB-9 connector marked SERIAL PORT 2 on the front panel. SERIAL PORT 2 is hardwired as an EIA-232-D DTE port. MVME712AM or MVME712-13: The DB-9 connector marked SERIAL PORT 2 OR the RJ-11 jack on the front panel. SERIAL PORT 2 is hardwired as EIA-232-D DTE; the RJ-11 jack utilizes the built-in modem. Setting the jumper headers J16 and J17 on the MVME712AM/-13 configures the output as EIA-232-D DTE at SERIAL PORT 2 or as a modem at the RJ-11 jack. Figure 2-3 (sheets 1 and 2) in Chapter 2 illustrates the two configurations available for Port A when the controller is used with an MVME712M. Figure 2-5 (sheets 1 and 2) shows the two configurations available for Port A when the controller is used with an MVME712A/AM/-12/-13. MVME162FX Serial Port 2 The configuration of B port of the Z85230 is determined via a Serial Interface Module (SIMM) which is installed at connector J10 on the controller. There are five SIMMS available: SIMM05 - DTE with EIA-232-D interface SIMM06 - DCE with EIA-232-D interface SIMM07 - DTE with EIA-530 interface SIMM08 - DCE with EIA-530 interface SIMM09 - EIA-485 interface, or DCE or DTE with EIA-422 interface Port B is routed, via the SIMM, to: ❏ The DB-25 connector marked SERIAL PORT 2 on the front panel of the MVME162FX controller. SERIAL PORT 2 will be an EIA232-D DCE or DTE port, or an EIA-530 DCE or DTE port, or an EIA-485 port, or an EIA-422 DCE or DTE port, depending upon which module is installed. Functional Description http://www.mcg.mot.com/literature 1-21 1 Note Port B is factory configured for asynchronous communication. For synchronous communication, this port can be connected to the TX and RX clock signals which may be present on the DB-25 connector. These connections are made via jumper header J12 on the controller. The TxC and RxC clock lines are available at the MVME712M SERIAL PORT 4 via header J15 on that board, but are not available on the other MVME712x transition modules. ❏ One of the following output connectors on the MVME712x transition module: MVME712M: The DB-25 connector marked SERIAL PORT 4 on the front panel. SERIAL PORT 4 can be configured as an EIA-232- D DTE or DCE port, via the jumper headers J18 and J19 on the MVME712M. MVME712A, AM, -12, or -13: The DB-9 connector marked SERIAL PORT 4 on the front panel. SERIAL PORT 4 is hard-wired as an EIA-232-D DTE port. Figure 2-3 (sheets 3 through 6) in Chapter 2 shows the four configurations available for Port B when the MVME162FX Embedded Controller is used with an MVME712M. Note that the port configurations shown in Figure 2-3, sheets 5 and 6 are not recommended for synchronous applications
