所用端子和硬件的额定值应与铝载体材料配合使用。PACSystems*RX3i系统手册第16节GFK-2314T 2019年9月专用模块796注意：星形锁紧垫圈方法适用于屏蔽接地，但不适用于安全接地。AWG#12（3.3mm2）或更大的电线从面板上去除油漆螺钉、星形锁紧垫圈、平垫圈、环形端子，安装在螺纹孔中。图413：接地连接图PACSystems*RX3i系统手册第16节GFK-2314T 2019年9月专用模块797 16.21.5.6在载体上安装模块I/O模块的插入和移除与RX3i通用背板相同。参考第2.6.4节。小心不要在CEP001或CEE001载体上安装电源模块。尝试这样做可能会损坏模块和/或载体。16.21.5.7不支持的模块当不支持的I/O模块插入RX3i CEP001载体或RX3i CEE001扩展载体时，不会报告任何警报来指示此情况。有关受支持I/O模块的最新更新列表，请参阅“受支持的I/O模块”一节。一些不受支持的I/O模块具有相同的区分类（例如，IC694MDL740与IC694MDL 742具有相同的区别类）。警告：如果在CEP001或CEE001载体中插入了不受支持的模块，则无法正确识别该模块，可能会损坏载体或模块。16.21.5.8连接电源您需要：注意：如果使用冗余电源，则需要两个电源。·一个24 Vdc电源，提供低压/限流（LVLC）电源。（例如，隔离直流电源和保险丝的组合，列出最小值为30 Vdc，最大值为3 a，与输入串联连接。）·28至16 AWG电线的电源线0.08至1.32 mm2电线·28至26 AWG电线的套圈（可选）·框架接地线，28至16 AWG.输入电源接线盒；提供（WAGO零件号713-1103）·小型平头螺丝刀（珠宝商尺寸14）PACSystems*RX3i系统手册第16节GFK-2314T 2019年9月特殊用途模块798注：出于CE标志的目的，CEP001载体的输入电源线应限制在30米（98英尺）或以下。注意：在将电线插入电源连接器接线盒之前，使用小平头螺丝刀松开接线盒上的弹簧夹。1.使用电源线，将电源连接到电源接线板，如图414所示。建议剥线长度为6至7毫米（0.25英寸）。如果使用冗余电源，请将第二个电源连接到输入电源接线板。3.将输入电源接线板插入输入电源连接器。注：CEP001载体中没有用户可维修的保险丝。16.21.5.9添加冗余电源▸为已在运行1的系统添加冗余电源。断开RX3i CEP001托架2的主电源。从托架上拆下电源接线板。将电源连接到RX3i CEP001载体图414：电源端子板CEP001图415:CEP001电源端子接线PACSystems*RX3i系统手册第16节GFK-2314T 2019年9月专用模块799 3。在不干扰主电源输入线的情况下，将冗余电源输入线连接到电源接线板。4.将电源接线板插入输入电源连接器。5.为冗余电源供电。RX3i CEP001载体上的PWR2 LED应亮起。向主电源供电。CEP001载体上的PWR1 LED应亮起。注意：有关更换冗余电源的程序，请参阅PACSystems RX3i PROFINET扫描仪IC695CEP001用户手册，GFK-2883。PACSystems*RX3i系统手册第16节GFK-2314T 2019年9月专用模块800 16.21.5.10将CEP001连接到PROFINET网络提供10/100 Mbps铜接口的两个外部RJ-45以太网端口位于CEP001载体的底部。图416：以太网端口CEP001设备的位置
Terminals and hardware used should be rated to work with the aluminum carrier material. PACSystems* RX3i System Manual Section 16 GFK-2314T Sept. 2019 Special Purpose Modules 796 Note: The star lock washer method is suitable for a shield ground, but not suitable for a safety ground. AWG #12 (3.3mm2 )or larger wire Paint removed from panel here Screw, star lock washer, flat washer, ring terminal, installed in tapped hole. Figure 413: Ground Connection Diagram PACSystems* RX3i System Manual Section 16 GFK-2314T Sept. 2019 Special Purpose Modules 797 16.21.5.6 Installing Modules on the Carrier The insertion and removal of I/O modules is the same as in an RX3i Universal Backplane. Refer to Section 2.6.4. CAUTION Do not install a Power Supply module on the CEP001 or CEE001 Carrier. Attempting to do so could damage the module and/or the Carrier. 16.21.5.7 Unsupported Modules When an unsupported I/O module is inserted into either the RX3i CEP001 Carrier or RX3i CEE001 Expansion Carrier, no alarm is reported to indicate this. For the latest updated list of supported I/O modules, refer to the section, Supported I/O Modules. Some unsupported I/O modules have the same Distinguishing Class (for example, IC694MDL740 has the same Distinguishing Class as IC694MDL742). CAUTION If an unsupported module is inserted in the CEP001 or CEE001 Carrier, the module will not be recognized correctly and could cause damage to the Carrier or the module. 16.21.5.8 Connecting Power Supplies You will need: Note: Two power supplies are required if using redundant power supplies. · One 24 Vdc power supply which provides a low voltage/limited current (LVLC) power source. (For example, the combination of an isolated DC supply and a fuse, listed 30 Vdc minimum and 3 A maximum, connected in series with the input.) · Power cord with 28 to16 AWG / 0.08 to1.32 mm2 wires · Ferrules for 28 to16 AWG wires (optional) · Frame ground wire, 28 to16 AWG · Input power terminal block; provided (WAGO Part Number 713-1103) · Small flathead screwdriver (jeweler’s size 14) PACSystems* RX3i System Manual Section 16 GFK-2314T Sept. 2019 Special Purpose Modules 798 Note: For CE Mark purposes, input power lines to the CEP001 Carrier should be limited 30 m (98 ft) or less. Note: Before inserting the wires into the power connector terminal block, use a small flathead screwdriver to release the spring clamp on the terminal block. 1. Using the power cord, attach the power supply to the power terminal block as diagrammed in Figure 414. Recommended wire stripping length is 6 to7 mm (0.25”). 2. If using redundant power supplies, connect the second power supply to the input power terminal block. 3. Insert the input power terminal block into the Input Power connector. Note: There are no user-serviceable fuses in the CEP001 Carrier. 16.21.5.9 Adding a Redundant Power Supply Ø To add a redundant power supply to a system that is already in operation 1. Remove power from the primary power supply to the RX3i CEP001 carrier 2. Remove the power terminal block from the carrier. Connecting Power to RX3i CEP001 Carrier Figure 414: Power Terminal Block CEP001 Figure 415: CEP001 Power Terminal Wiring PACSystems* RX3i System Manual Section 16 GFK-2314T Sept. 2019 Special Purpose Modules 799 3. Without disturbing the primary power supply input lines, connect the redundant power supply input lines to the power terminal block. 4. Insert the power terminal block into the Input Power connector. 5. Apply power to the redundant power supply. The PWR2 LED on the RX3i CEP001 carrier should turn on. 6. Apply power to the primary power supply. The PWR1 LED on the CEP001 Carrier should turn on. Note: For the procedure to swap a redundant power supply, refer to PACSystems RX3i PROFINET Scanner IC695CEP001 User Manual, GFK-2883. PACSystems* RX3i System Manual Section 16 GFK-2314T Sept. 2019 Special Purpose Modules 800 16.21.5.10 Connecting the CEP001 to the PROFINET Network The two external RJ-45 Ethernet ports, which provide 10/100 Mbps copper interfaces, are on the bottom of the CEP001 Carrier. Figure 416: Locations of Ethernet Ports CEP001 Devices
